Chevrolet Corvette 2019 Fuse Box Info
Luggage compartment fuse box location:
The rear compartment fuse box is in the rear of the vehicle, under the load floor.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Luggage compartment fuse box:
| Fuse/Relay N° | Functions |
| Fuses | |
| 1 | Window |
| 2 | Driver Power Seat |
| 3 | Passive entry/ Passive start 2 |
| 4 | Passive entry/ Passive start 1 |
| 5 | Engine Control Module |
| 6 | Heated Mirrors |
| 7 | Body Control Module 4 |
| 8 | Rear Window Defogger |
| 9 | GBS |
| 10 | Body Control Module 2 |
| 11 | Steering Wheel |
| 12 | Passenger Power Seat |
| 13 | - |
| 14 | Exterior rearview mirror |
| 15 | Body Control Module 1 |
| 16 | Body Control Module 3 |
| 17 | Sensing Diagnostic Module/Automatic Occupant Sensing |
| 18 | Logistics 2 |
| 19 | Body Control Module 8 |
| 20 | Integrated Chassis Control Module |
| 21 | Amplifier |
| 22 | Rear Accessory Power Outlet |
| 24 | Memory Seat Module/ Convertible Top |
| 25 | Theft deterrent PSM |
| 26 | Trunk release module |
| 27 | OnStar (If Equipped) |
| 28 | Camera Module |
| 29 | - |
| 30 | Fuel Pump Power Module |
| 31 | Trunk release module latch |
| 32 | Battery Regulated Voltage Control |
| 33 | - |
| 34 | Convertible Top Solenoid |
| 35 | - |
| 36 | Passenger Window Switch |
| 37 | Front Accessory Power Outlet |
| 38 | - |
| 39 | - |
| 40 | - |
| 41 | - |
| 42 | - |
| 43 | - |
| 44 | - |
| Relays | |
| R1 | - |
| R2 | Rear Window Defogger |
| R3 | - |
| R4 | Front Accessory Power Outlet |
| R5 | Theft (Door Lock Security) |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| Fuses | |
| 2 | ECM power ignition 2/– |
| 3 | Front HVAC |
| 7 | ABS pump |
| 9 | –/ECM power ignition |
| 12 | Transmission cooling rear fan 2 |
| 14 | Heated seat module battery supply |
| 16 | Column lock module |
| 17 | Steering tilt and telescope |
| 18 | CGM |
| 19 | – / Fuel injector control module power ignition 1 |
| 20 | Integrated chassis control module automatic occupant sensing |
| 21 | Glove box door |
| 23 | Engine inside position / ECM power ignition 3 |
| 25 | Body control module 6 |
| 28 | HVAC controls |
| 29 | Front wiper |
| 30 | Body control module 5 |
| 31 | Heated seat module / run,crank supply |
| 32 | Starter |
| 36 | Body control module 7 |
| 39 | Intrusion module / Human machine interface module |
| 40 | Steering column lock |
| 41 | ABS valves |
| 43 | - / Fuel tank zone module batt |
| 44 | Center stack |
| 45 | Auxiliary outlet |
| 46 | Radio |
| 47 | Display |
| 48 | Interior rearview mirror |
| 49 | Logistics |
| 50 | Engine / Transmission |
| 51 | Ignition – odd |
| 52 | Ignition – even |
| 53 | Fuel pump prime / Miscellaneous powertrain loads |
| 54 | - / Fuel injector control module power ignition 2 |
| 55 | Engine control module 1 |
| 58 | Data link connector |
| 63 | Seat fan |
| 64 | Fuel pump power module |
| 65 | Cluster |
| 67 | Exhaust valve 1 |
| 71 | Horn |
| 73 | – / Fuel tank zone module ignition |
| 74 | Headlamp wash |
| 75 | AC clutch |
| 76 | – / Rear transmission coolant pump |
| 77 | Engine outside position |
| 78 | Engine control module 2 / Transmission control module |
| 79 | Electric parking brake |
| 81 | Continuous variable real time dampening |
| 82 | Intercooler |
| 83 | Left headlamp |
| 84 | Right headlamp |
| 85 | High-beam headlamps |
| 86 | Washer pump |
| 87 | Exhaust valve 2 |
| 88 | Reverse lockout |
| 90 | Electronic Limited slip differential 1 |
| 92 | Vacuum pump |
| 93 | Transmission cooling rear fan 1 |
| 94 | Electronic Limited slip differential 2 |
| 95 | Transmission control module |
| 97 | Canister vent valve |
| Spare Fuses | |
| 1 | Spare |
| 2 | Spare |
| 3 | Spare |
| 4 | Spare |
| 5 | Spare |
| 6 | Spare |
| 7 | Spare |
| 8 | Spare |
| 9 | Spare |
| 10 | Spare |
| 11 | Spare |
| Relays | |
| K2 | – / Engine control module |
| K3 | Starter |
| K4 | Front wiper, Low-High |
| K5 | Run-Crank |
| K8 | Front wiper on off |
| K10 | Fuel pump prime |
| K11 | Engine control module / – |
| K15 | Headlamp washer |
| K17 | AC control |
| K18 | Vacuum pump |
| K21 | Low beam headlamps |
