Chevrolet Corvette 2005 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the passenger’s side of the vehicle, under the instrument panel and under the toe-board.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay Name | Functions |
| SPARE FUSE HOLDER |
Spare Fuse Holder |
| SPARE FUSE HOLDER |
Spare Fuse Holder |
| SPARE FUSE HOLDER |
Spare Fuse Holder |
| SPARE FUSE HOLDER |
Spare Fuse Holder |
| SPARE | Spare |
| ONSTAR | OnStar® |
| DRIV DR SW | Driver Door Switch |
| TELE SW/MEM SEAT MOD |
Telescope Switch, Memory Seat Module |
| IGN SW/INTR SENS |
Ignition Switch, Intrusion Sensor |
| REVERSE LAMP |
Reverse Lamp |
| REVERSE LAMPS |
Reverse Lamps |
| Blank | Not Used |
| STOP LAMP | Stop Lamp |
| BTSI SOL/COL LOCK |
Brake Transmission Shift Interlock, Column Lock |
| BLANK | Not Used |
| RADIO/S- BAND/VICS |
Radio, S-Band, VICS |
| REAR FOG/ALDL/TOP SW |
Rear Fog Lamp, Assembly Line Diagnostic Link Connector, Convertible Top Switch |
| GMLAN DEVICES |
GMLAN Devices |
| ISRVM/ HVAC | Electric Inside Rearview Mirror, Heating Ventilation, Air Conditioning |
| CRUISE SW | Cruise Control Switch |
| TONNEAU RELSE |
Tonneau Release |
| RUN/CRANK | Run/Crank Relay |
| HTD SEAT/ WPR RELAYS |
Heated Seat, Wiper Relays |
| ECM | Engine Control Module |
| SDM PSIR SW AIRBAG |
SDM/PSIR Switch (Airbag) |
| CLSTR/HUD | Cluster, Heads-Up Display |
| HVAC/PWR SND |
Heating, Ventilation/Air Conditioning, Power Sounder |
| SPARE | Spare |
| DR LCK | Door Locks |
| CTSY/LAMP | Courtesy Lamp |
| BLANK | Not Used |
| TONNEAU RELSE |
Tonneau Release |
| TRUNK RELSE | Trunk Release |
| REAR/ FOG | Rear Fog Lamps |
| FUEL DR RELSE |
Fuel Door Release |
| BLANK | Not Used |
| BLANK | Not Used |
| CIG LTR | Cigarette Lighter |
| DRVR HTD SEAT |
Driver’s Heated Seat |
| WPR DWELL | Wiper Dwell |
| BLANK | Not Used |
| AUX PWR | Auxiliary Power |
| PASS HTD SEAT |
Passenger’s Heated Seat |
| BLANK | Not Used |
| PWR WNDWS/FUEL RELSE |
Power Windows, Fuel Door Release |
| TRUNK RELSE | Trunk Release |
| PWR LUMBAR | Power Lumbar |
| BLANK | Not Used |
| PWR SEATS MEMORY SEATS |
Power Seats, Memory Seats |
| BLANK | Not Used |
| BLANK | Not Used |
| WPR/WASHER | Windshield Wiper/Washer |
| BLANK | Not Used |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| Fuses | |
| 1 | Transmission Control Module/Transmission |
| 2 | Horn, Alternator Sense |
| 3 | Anti-lock Brakes/Real Time Damping |
| 4 | Wiper |
| 5 | Stoplamps/Back-Up Lamps |
| 6 | 02 Sensor |
| 7 | Battery Main 5 |
| 8 | Park Lamps |
| 9 | Powertrain Relay Input/Electronic Throttle Control |
| 10 | Manual Transmission Solenoids |
| 11 | Engine Control Module/Transmission Control Module/Easy Key Module |
| 12 | Odd Numbered Fuel Injectors |
| 13 | Real Time Damping |
| 14 | Canister Purge Solenoid, Mass Air Flow Sensor |
| 15 | Air Conditioner Compressor |
| 16 | Even Numbered Fuel Injectors |
| 17 | Windshield Washer |
| 18 | Headlamp Washer |
| 19 | Right Low-Beam |
| 20 | Fuel Pump |
| 21 | Left Low-Beam |
| 22 | Front Fog Lamp |
| 23 | Right High-Beam |
| 24 | Left High-Beam |
| 25 | Cooling Fan |
| 26 | Battery Main 3 |
| 27 | Anti-Lock Brake System |
| 28 | Heating/Ventilation/Air Conditioning Blower |
| 29 | Battery Main 2 |
| 30 | Starter |
| 31 | Audio Amplifier |
| 32 | Blank |
| 33 | Battery Main 1 |
| Spare Fuses | |
| 48 | Spare |
| 49 | Spare |
| 50 | Spare |
| 51 | Spare |
| 52 | Spare |
| 53 | Spare |
| 54 | Fuse Puller |
| Relays | |
| 34 | Horn |
| 35 | Air Conditioning Compressor |
| 36 | Windshield Washer |
| 37 | Park, Position Lamps |
| 38 | Front Fog Lamp |
| 39 | High Beam |
| 40 | Rear Defog |
| 41 | Windshield Wiper High/Low |
| 42 | Windshield Wiper Run/Accessory |
| 43 | Crank |
| 44 | Powertrain Ignition 1 |
| 45 | Windshield Wiper On/Off |
| 46 | Headlamp Washer |
| 47 | Low Beam |
| 55 | Fuel Pump |
| Diodes | |
| Diode 1 | |
| Wiper | |
| Diode 2 |
