Buick Park Avenue 2000 Fuse Box

Buick Park Avenue 2000 Fuse Box Info


Passenger compartment fuse box location:

The instrument panel fuse box is is located to the far right side under the instrument panel.

The fuse box is is located under the rear seat.


Engine compartment fuse box location:



Fuse Box Diagram | Layout


Passenger compartment fuse box (under the instrument panel):

Fuse/Relay Functions
SBM Interior Lamps
PDM PDM Module
A/C HVAC Motor, HVAC Mix Motors
IGN SEN EC Mirror, Driver HTS Seat, Rear Defog Relay, MEM Module, Cool LVL Sensor, Pass Heated Seat
ELC HVAC Flat Pk Mtrs, ELC Sensor, ELC Sensor (R Bec)
ABS Anti-Lock Brake System Module
HVAC  HVAC Main Con Head, HVAC Programmer, IPC
CR CONT Stepper Motor CR, Cruise Switch
HUD HUD Switch, HUD Display
CSTR/SBM HVAC Programmer, IPC (Cluster), SBM (275 to LCM) (1135 to BTSI SL)
LP PK L Underhood Lamp, L PK/Sidemarker, L Park/Turn Lamp, SBM, L Tail Signal Lamp, L Tail/Stop Lamp, L Rear Sidemarker
LP PK R Rt Pk/Sidemarker Lamp, Rt PK/Turn Lamp, Rt Tail/Sign Lamp, Rt Tail/Stoplamp, Rt Rear Sidemarker, Stop/Tail Lamp, Tail/Signal Lamp, License Lamp, RFA
RUN Run/Accessory
WSW Wiper Motor
EMPTY Not Used
WSW/RFA Wiper Switch, RFA, Rain Sense
B/U LP EC Mirror, Back-Up Lamps


Passenger compartment fuse box (under the rear seat):

Fuse/Relay Functions
1 Heated Backlite
2 Rap
3 Trunk Release
5 Power Seat
6 ELC Sensor, ELC Compressor Solenoid
7 Crank
8 Auxiliary Outlet
10 SBM Module
11 Radio/Phone
12 Sunroof
13 Spare
14 CD Changer, Phone
15 Driver Door Module
16 Spare
17 Radio
18 Driver Heated Seat Module
19 Rear Door Module
20 Trunk Release
21 Spare
22 IP Ashtray Cigarette Lighter
23 Spare
24 Spare
25 Passenger Heated Seat Module
26 Right Rear Cig Lighter
27 Left Rear Cig Lighter
28 RFA, Memory Seat Module, Driver Seat Switch


Engine compartment fuse box:

Fuse/Relay Functions
1 Air Sol
3 Turn Signal
4 Pre-Oxygen Sensor, Post-Oxygen Sensor
5 Air Bag (SIR)
7 AC Clutch
8 Ignition Feed
9 Horn Relay
10 Spare
11 Spare
12 Injectors #1-6
13 C-31
14 Right High Beam
15 Spare
16 Left High Beam
17 Spare
18 Right Low Beam
19 Left Low Beam
20 Stop
21 Fuel Pump Relay (Wire in BEC)
22 Run/CRK
23 PCM
24 Parking Lamp
25 Hazard Flashers
26 Spare
27 Spare
28 ABS #2
29 Ignition
30 Horn
31 Cool Fan #2
32 Starter
33 Air Pump
34 Cool Fan SP
35 Cool Fan 1
36 A/C CLU
37 Fuel Pump
38 Bat #1
39 Blower Motor
40 Cool Fan 2
41 Headlamp
42 BAT #2
43 Ignition
44 Starter
45 ABS
46 Fuse Puller
