Buick Verano 2013 Fuse Box

Buick Verano 2013 Fuse Box Info



Fuse box location:

The instrument panel fuse box is on the underside of the driver side instrument panel.



Engine compartment fuse box:



Luggage compartment fuse box:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
Fuses
1 2A Body Control Module
2 20A Body Control Module
3 20A Body Control Module
4 20A Infotainment System
5 10A Information Display/ Parking Assist
6 20A Ignition/ Electronic Key System
7 20A Power Outlet
8 20A Body Control Module
9 20A Body Control Module
10 20A Body Control Module
11 40A Interior Fan
12 25A Driver Power Seat
13 - Not used
14 7.5A Diagnostic Connector
15 10A Airbag
16 10A Central Locking System/ Tailgate
17 10A Air Conditioning System
18 30A Infotainment System
19 30A Body Control Module
20 5A Passenger Power Seat
21 7.5A Instrument Cluster
22 2A/5A Ignition/ Electronic Key System
23 20A Body Control Module
24 20A Body Control Module
25 - Not used
26 - Not used
Relays
1   Trunk Open
2   Door Security
3   Power Outlet




Engine compartment fuse box:

Fuse/Relay N°   Functions
Mini Fuses
1 20A Engine Control Module
2 10A Oxygen Sensor/Purge Solenoid
3 15A Ignition Coils/ Injectors
4 15A Spare
5 - Empty
6a - Empty
6b 7.5A Mirror Defogger
7 5A Powertrain Cooling
8 7.5A Mass Air Flow Sensor/ Pre O2 Sensor
9 - Empty
10 5A Battery Potential Signal
11 7.5A Spare
12 - Empty
13 25A Antilock Brake System Valves
14 - Empty
15 10A Engine Control Module
17 10A Transmission Control Module
22 - Empty
24 15A Right High-Beam Headlamp
25 15A Left High-Beam Headlamp
26 15A Front Fog Lamps
31 - Empty
32 5A Airbag
33 - Empty
34 7.5A Spare
35 7.5A Door Switch Supply/Left Power Window
36 10A Air Conditioning Compressor Clutch
37 10A Canister Vent
38 - Empty
39 20A Fuel System Control Module
40 10A Front Windshield Washer
41 - Empty
46 - Empty
47 15A Horn
49 20A Fuel Pump
50 - Empty
51 5A Inside Rear View Mirror
52 - Empty
53 10A Ignition Engine Control Module/ Transmission Control Module
54 7.5A Instrument Cluster/Fuel System Control Module/ Heater, Ventilation, and Air Conditioning Run/Crank
J-Case Fuses
16 30A Starter Control
18 30A Rear Window Defogger
19 30A Front Power Window
20 30A Rear Power Window
21 40A Rear Electrical Center
23 - Empty
27 50A Spare
28 - Empty
29 30A Electric Parking Brake
30 60A Antilock Brake System Pump
42 40A Engine Cooling Fan (RPO LEA)
43 30A Front Wipers
44 - Empty
45 30A Engine Cooling Fan (RPO LEA)
48 60A Engine Cooling Fan
Relays
1   Empty
2   Starter
3   Engine Control Powertrain
4   Rear Window Defogger
5   Empty
6   Empty
7   Spare
8   Empty
9   Spare
10   EGR/Coolant Pump/ AIR Solenoid Valve
11   Engine Cooling Fan (RPO LEA)
12   Engine Cooling Fan (RPO LEA)
13   Engine Cooling Fan (RPO LEA)
14   Run/Crank





Luggage compartment fuse box:

Fuse/Relay N°   Functions
Mini Fuses
F02 - Empty
F03 5A Rear Park Assist
F04 - Empty
F06 - Empty
F07 10A Spare
F08 - Empty
F09 - Empty
F10 - Empty
F11 - Empty
F13 - Empty
F14 - Empty
F15 - Empty
F16 5A Rear Vision Camera
F17 - Empty
F18 - Empty
F19 7.5A Heated Steering Wheel
F20 25A Sunroof
F21 25A Heated Seats
F22 - Empty
F24 - Empty
F25 5A Side Blind Zone Alert
F26 30A Spare
F28 - Empty
F30 - Empty
F31 30A Amplifier
J-Case Fuses
F01 - Empty
F05 - Empty
F12 - Empty
F23 - Empty
F27 30A Passive Entry
F29 - Empty
Relays
R01   Empty
R02   Run
R03   Empty
R04   Empty
R05   Empty
