Acura EL 2005 Fuse Box

Acura EL 2005 Fuse Box Info



Passenger compartment fuse box location:

The interior fuse box is located underneath the steering column.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
1 15A Ignition Coil
2 20A LAF Heater
3 10A Daytime Running Lights
4 10A Alternator
5 - Not Used
6 7.5A Power Window Relay
7 20A Moonroof
8 7.5A Accessory, Radio
9 - Not Used
10 7.5A Meter
11 7.5A ABS
12 7.5A Daytime Running Lights
13 10A SRS
14 10A Remote Control Mirrors
15 20A Front Fog Light
16 20A Heated Seat
17 15A Fuel Pump
18 15A Accessory Power Sockets
19 7.5A Turn Signal Lights
20 20A Front Wiper
21 - Not Used
22 20A Front Right Power Window
23 20A Front Left Power Window
24 20A Rear Left Power Window
25 20A Rear Right Power Window



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
1 20A Condenser Fan
2 15A Small Light
3 7.5A Interior Light
4 20A Cooling Fan
5 10A Hazard
6 15A FI ECU
7 15A Horn, Stop
8 20A ABS F/S
9 10A Back Up
10 40A ABS Motor
11 30A Rear Defroster
12 40A Heater Motor
13 40A Power Window
14 40A Option
15 15A Left Headlight
16 20A Door Lock
17 15A Right Headlight
18 - Not Used
19 80A Battery
20 40A Ignition 1
21-25 7.5A-30A Spare Fuses
