Acura CSX 2009 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is located under the dashboard on the driver’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | IG1 Power Window |
| 2 | 15A | Fuel Pump |
| 3 | 10A | Alternator |
| 4 | 7.5A | IG1 ABS/VSA |
| 5 | (15A) | Heated Seat |
| 6 | (20A) | Front Fog |
| 7 | (7.5A) | TPMS |
| 8 | - | Not Used |
| 9 | 7.5A | IG1 ODS |
| 10 | 7.5A | METER |
| 11 | 10A | SRS |
| 12 | 10A | Right Headlight High |
| 13 | 10A | Left Headlight High |
| 14 | 7.5A | Small (Interior) |
| 15 | 7.5A | Small (Exterior) |
| 16 | 10/15A*1 | Right Headlight Low |
| 17 | 10/15A*1 | Left Headlight Low |
| 18 | 20A | Headlight High Main |
| 19 | 15A | Small (Main) |
| 20 | - | Not Used |
| 21 | 20/30A*1 | Headlight Low Main |
| 22 | (7.5A) | IG1 HAC*2 |
| 23 | (7.5A) | STS |
| 24 | (20A) | Moonroof |
| 25 | 20A | Door Lock |
| 26 | 20A | Driver’s Power Window |
| 27 | (20A) | Option |
| 28 | (15A) | Rear ACC Socket |
| 29 | 15A | ACC |
| 30 | 20A | Passenger’s Power Window |
| 31 | - | Not Used |
| 32 | 20A | Right Rear Power Window |
| 33 | 20A | Left Rear Power Window |
| 34 | - | Not Used |
| 35 | 7.5A | ACC Radio |
| 36 | 10A | IG2 HAC |
| 37 | 7.5A | Daytime Running Light |
| 38 | 30A | FR Wiper |
*1 High voltage discharge type
*2 Except Type S
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 |
100A (70A) |
Main Fuse EPS |
| 2 |
60A 50A |
Option Main Ignition Switch Main |
| 3 |
30A 40A |
ABS/VSA motor ABS/VSA F/S |
| 4 |
50A 40A |
Headlight Main Power Window Main |
| 5 | - | Not Used |
| 6 | 20A | Sub Fan Motor |
| 7 | 20A | Main Fan Motor |
| 8 | 30A | Rear Defogger |
| 9 | 40A | Blower |
| 10 | 10A | Hazard |
| 11 | 15A | FI Sub |
| 12 | 15A | Stop and Horn |
| 13 | - | Not Used |
| 14 | - | Not Used |
| 15 | 7.5A | Oil Level |
| 16 | - | Not Used |
| 17 | (15A) | Audio Amp |
| 18 | 15A | IG Coil |
| 19 | 15A | FI Main |
| 20 | 7.5A | MG Clutch |
| 21 | 15A | DBW |
| 22 | 7.5A | Interior Light |
| 23 | 10A | Back Up |
