Acura RL 2006 Fuse Box

Acura RL 2006 Fuse Box Info



Passenger compartment fuse box location:

The interior fuse box A is located on the lower driver’s side panel. The internal fuse box B is located on the right side of the steering wheel, under the dashboard. The interior fuse box C is located on the lower passenger’s side panel.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box A (Driver’s side):

Fuse/Relay N° Rating Functions
1 15A Drive by Wire
2 15A Ignition coil
3 10A Daytime running light
4 15A Laf heater
5 7.5A Radio
6 7.5A Interior light
7 10A Back-up
8 20A Door lock
9 20A Accessory socket
10 7.5A Occupant position detection system
11 7.5A Wiper
12 7.5A Tire pressure monitoring system
13 20A Passenger’s power seat reclining
14 20A Driver’s power seat sliding
15 10A Power lumbar support
16 20A Driver’s power seat reclining
17 20A Passenger’s power seat sliding
18 15A ACG
19 20A Fuel Pump
20 15A IGN SOL
21 7.5A Meter
22 10A SRS
23 7.5A IGP (PGM-FI ECU)
24 20A Left rear power window
25 20A ETS (telescopic)
26 20A ETS (tilt)
27 30A Driver’s power window
28 20A Moonroof
29 7.5A AFS
30 7.5A A/C
31 7.5A SH-AWD
32 10A ACC
33 (7.5A) Option



Passenger compartment fuse box B:

Fuse/Relay N° Rating Functions
1 7.5A Starter diag.
2 7.5A Starter signal



Passenger compartment fuse box C (Passenger’s side):

Fuse/Relay N° Rating Functions
1 30A SH-AWD
2 30A Premium amplifier
3 30A Passenger’s power window
4 30A Driver’s automatic seat belt tensioner
5 20A Right rear power window
6 20A Heated seats
7 7.5A Interior lights
8 30A Passenger’s automatic seat belt tensioner/e-pretensioner
9 7.5A Air conditioner



Engine compartment fuse box (Primary):

Fuse/Relay N° Rating Functions
1 15A Left headlight low beam
2 30A Rear defroster coil
3 10A Left headlight high beam
4 15A Small light
5 10A Right headlight high beam
6 15A Right headlight low beam
7 7.5A Back-up
8 15A FI ECU
9 30A Wiper
10 30A Headlight washer*
11 20A Fog lights
12 7.5A MG clutch
13 15A Horn, Stop
14 40A Rear defroster
15 40A Back-up, ACC
16 15A Hazard
17 30A VSA motor
18 40A VSA
19 40A Drive by wire, Laf heater
20 - Not used (OP)
21 40A Heater motor
22

70A

120A

Passenger’s fuse box

Battery

23

50A

50A

IG main

Power window

* Not available on all models



Engine compartment fuse box (Secondary) - fuse box is on the battery:

Fuse/Relay N° Rating Functions
1 50A Radiator fan
