Acura RL 2003 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is underneath the dashboard on the driver’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Small Light |
| 2 | - | Not Used (OP) |
| 3 | 7.5A | Rear Window Defogger Relay, Cooling Fan Relay |
| 4 | 10A | Radio, ACC |
| 5 | 20A | A/C Clutch, Heated Seat |
| 6 | 20A | ECU (PCM) |
| 7 | 10A | SRS |
| 8 | 20A | Driver’s Power Seat |
| 9 | 20A | Bose Audio System |
| 10 | 10A | Daytime Running Lights* |
| 11 | 20A | Driver’s Power Seat |
| 12 | 7.5A | Daytime Running Lights* |
| 13 | 7.5A | Meter, Moonroof |
| 14 | 7.5A | Starter Signal |
| 15 | 7.5A | ACG |
| 16 | 10A | ACC Socket |
| 17 | 7.5A | Power Window MPCS |
| 18 | 20A | Front Right Power Window |
| 19 | 7.5A | Mirror |
| 20 | 20A | ECU (Body) |
| 21 | 20A | Rear Right Power Window |
| 22 | 20A | Fuel Pump |
| 23 | 7.5A | SRS |
| 24 | 20A | Rear Left Power Window |
| 25 | 30A | Ignition Coils |
| 26 | - | Not Used |
* Not available on all models
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Not Used |
| 2 | 20A | Stop, Horn |
| 3 | 10A | Hazard |
| 4 | 20A | Driver Power Window |
| 5 | 15A | TCS |
| 6 | 20A | VSA |
| 7 | 20A | Power Door Lock |
| 8 | 20A | Right Headlight Low |
| 9 | 20A | Left Headlight Low |
| 10 | 20A | Cooling Fan |
| 11 | 10A | Left Headlight High |
| 12 | 10A | Right Headlight High |
| 13 | 20A | Condenser Fan |
| 14 | 30A | Moonroof |
| 15 | 30A | Front Passenger’s Power Seat |
| 16 | 20A | Front Fog Light |
| 17 | 20A | ETS (Electrical Tilt/Telescope Steering) |
| 18 | 15A | Meter |
| 19 | 7.5A | Back-up, Radio |
| 20 | 20A | Interior Lights |
| 21 | 30A | Wiper Motor |
| 22 | 50A | Ignition Switch |
| 23 | 40A | Power Window |
| 24 | 40A | Heater Motor |
| 25 | 120A | Battery |
| 26 | 40A | VSA Motor |
| 27 | 40A | Rear Window Defogger |
| 28 | 50A | Fuse box |
