Acura RDX 2015 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is located under the dashboard.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | - |
| 2 | 15A | ACG |
| 3 | 10A | SRS |
| 4 | 15A | Fuel Pump |
| 5 | 7.5A | Meter |
| 6 | 7.5A | Option |
| 7 | 10A | VB SOL |
| 8 | 15A | Front Right Side Door Lock Motor (Unlock) |
| 9 | 15A | Rear Left Side Door Lock Motor (Unlock) |
| 10 | 7.5A | Power Lumbar |
| 11 | 20A | Moonroof |
| 12 | 15A | Accessory Power Socket (Center Console) |
| 13 | 15A | Washer Main |
| 14 | 15A | Seat Heaters |
| 15 | 10A | Driver’s Door Lock Motor (Unlock) |
| 16 | - | - |
| 17 | - | - |
| 18 | - | - |
| 19 | 7.5A | ACC |
| 20 | 7.5A | ACC Key Lock |
| 21 | 7.5A | Daytime Running Lights |
| 22 | 7.5A | A/C |
| 23 | 10A | Rear Wiper |
| 24 | 7.5A | ABS/VSA |
| 25 | - | - |
| 26 | 20A | Audio Amp |
| 27 | 15A | Accessory Power Socket (Front) |
| 28 | - | - |
| 29 | 7.5A | ODS |
| 30 | 10A | Driver’s Door Lock Motor (Lock) |
| 31 | 10A | Smart |
| 32 | 15A | Front Right Side Door Lock Motor (Lock) |
| 33 | 15A | Rear Left Side Door Lock Motor (Lock) |
| 34 | 7.5A | Small Lights |
| 35 | 7.5A | Illumination |
| 36 | 10A | Rear Wiper Main |
| 37 | - | - |
| 38 | 10A | Left Headlight High Beam |
| 39 | 10A | Right Headlight High Beam |
| 40 | 7.5A | TPMS |
| 41 | 20A | Door Lock |
| 42 | 20A | Driver’s Power Window |
| 43 | 20A | Rear Right Side Power Window |
| 44 | 20A | Front Right Side Power Window |
| 45 | 20A | Rear Left Side Power Window |
| 46 | 30A | Wiper |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 |
70A (40A) 20A 40A 30A 100A |
EPS Power Tailgate Motor* ABS/VSA FSR ABS/VSA Motor E-DPS Main Fuse |
| 2 |
50A 60A 60A 50A (30A) 30A 40A 30A 30A 40A |
ST CUT Fuse Box Main 1 Fuse Box Main 2 IG Main Headlight Washer Sub Fan Motor Rear Defogger Main Fan Motor Headlight Main Blower |
| 3 |
20A 20A 20A 20A |
Driver's Power Seat Sliding Driver's Power Seat Reclining Passenger's Power Seat Sliding Passenger's Power Seat Reclining |
| 4 | - | - |
| 5 | 7.5A | STR Diagnosis Fuse |
| 6 | - | - |
| 7 | - | - |
| 8 | - | - |
| 9 | - | - |
| 10 | - | - |
| 11 | 7.5A | Oil Level |
| 12 | (20A) | Fog Lights* |
| 13 | (20A) | Power Tailgate Closer* |
| 14 | 10A | Hazard |
| 15 | 15A | IGP2 |
| 16 | 15A | IG Coil |
| 17 | 15A | Stop |
| 18 | 10A | Horn |
| 19 | 10A | ACM |
| 20 |
10A*1 15A*2 |
Right Headlight Low Beam |
| 21 | 7.5A | MG Clutch |
| 22 | 15A | DBW |
| 23 |
10A*1 15A*2 |
Left Headlight Low Beam |
| 24 | 10A | ACC |
| 25 | (15A) | FI Main |
| 26 | (20A) | Trailer |
| 27 | 20A | Small |
| 28 | 7.5A | Interior Lights |
| 29 | 10A | Backup |
* Not available on all models
*1: Models with halogen low beam headlight bulbs
*2: Models with high voltage discharge tube bulbs
