Acura MDX 2005 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse boxes are located under the dashboard on the driver’s and passenger’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box A (Driver’s Side):
Fuse/Relay N° | Rating | Functions |
1 | 15A | Fuel Pump |
2 | 10A | SRS |
3 | 7.5A | Heater Control, A/C Clutch Relay, Cooling Fan Relay |
4 | 7.5A | Power Mirror |
5 | 10A | Daytime Running Light* /Rear Wiper |
6 | 15A | ECU (PCM), Cruise Control |
7 | 7.5A | OPDS, OnStar |
8 | 7.5A | ACC Relay |
9 | 10A | Back-up Lights, Instrument Lights, TPMS |
10 | 7.5A | Turn Signals |
11 | 15A | IG Coil |
12 | 30A | Front Wiper |
13 | - | Not Used |
* On Canadian models
Passenger compartment Auxiliary fuse box: (Driver’s Side):
Fuse/Relay N° | Rating | Functions |
1 | 7.5A | Horn |
2 | 7.5A | ELD Unit, Immobilizer Control Unit, VSA Control Unit, Alternator |
3 | 7.5A | Auto Wipers |
Passenger compartment fuse box B (Passenger’s Side):
Fuse/Relay N° | Rating | Functions |
1 | 30A | Moonroof |
2 | 20A | Driver’s Power Seat Reclining |
3 | 30A | Passenger’s Power Seat Sliding |
4 | 20A | Driver’s Power Seat Sliding |
5 | 20A | Passenger’s Power Seat Reclining |
6 | 10A | Daytime Running Light, OnStar* |
7 | 20A | Driver’s side Rear Power Window |
8 | 20A | Front Passenger’s Power Window |
9 | 15A | Front Accessory Socket, HFL, OnStar |
10 | 15A | Small Light |
11 | 10A | Interior Light, TPMS, HFL |
12 | 20A | Power Door Lock |
13 | 7.5A | Back Up, Clock |
14 | 20A | Heated Seat |
15 | 20A | Driver’s Power Window |
16 | 20A | Passenger’s Side Rear Power Window |
* On Canadian models
Engine compartment fuse box A (Primary):
Fuse/Relay N° | Rating | Functions |
1 | 20A | Spare Fuse |
2 | 30A | Spare Fuse |
3 | 20A | Right Headlight |
4 | 15A | ACG S |
5 | 15A | Hazard |
6 | - | Not Used |
7 | 20A | Stop |
8 | 20A | Left Headlight |
9 | 20A | Radio |
10 | 40A | Power Window Motor |
11 | 30A | Rear A/C |
12 | 30A | Rear Defroster |
13 | 40A | Back Up, ACC |
14 | 40A | Power Seat |
15 | 40A | Heater Motor |
16 | 30A | Cooling Fan |
17 | 7.5A | Spare Fuse |
18 | 10A | Spare Fuse |
19 | 15A | Spare Fuse |
20 | 120A | Battery |
21 | 30A | Condenser Fan |
22 | 7.5A | MG Clutch |
23 | 50A | IGI Main |
24 | 20A | Fog Lights |
Engine compartment fuse box B (Secondary):
Fuse/Relay N° | Rating | Functions |
1 | 20A | 4WD |
2 | 40A | VSA F/S Relay |
3 | 30A | VSA Motor |
4 | 20A | Rear Entertainment System |
5 | 20A | Rear Accessory Socket |
6 | 15A | ETC |
7 | 15A | IG Coil |
8 | 15A | LAF |
9 | 7.5A | FI-Back-up |
10 | 20A | P/W DR |
