Alfa Romeo MiTo 2015 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located on the driver's side under the instrument panel.
Engine compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay N° | Rating | Functions |
12 | - | Available |
13 | 5A | Headlamp alignment corrector |
31 | 5A | INT/A relay for engine compartment junction unit |
36 | 15A | EOBD diagnosis port supply, radio, Bluetooth®, radionavigator (where provided), alarm siren; alarm volumetric sensors, electric fan, TPMS, electric mirror controls, climate control system controls |
37 | 5A | Brake light switch (NO), instrument panel node, headlight alignment corrector |
38 | 15A | Doors and luggage compartment central locking |
43 | 20A | Windscreen/rear window washer pump |
47 | 20A | Electric window (driver side) |
48 | 20A | Electric window (passenger side) |
49 | 5A | Parking sensors, control lighting, electrochromic mirror, rain/dusk sensor, soft top, TMPS; cigar lighter lighting, SBR system panel |
51 | 5A | Climate control system controls, radio preparation system; Bluetooth®, brake light switch (NC), clutch switch, reverse switch, flow meter (diesel versions), water in diesel filter sensor (diesel versions) |
53 | 5A | Instrument Panel Node |
Engine compartment fuse box:
Fuse/Relay N° | Rating | Functions |
03 | 20A | Starter |
08 | 40A | Passenger compartment electric fan |
09 | 5A | Additional heater (Turbo TwinAir 105 HP and 1.3 JTDM-2 85 HP versions) |
10 | 15A | Two-tone horns |
14 | 15A | Main beam headlights |
15 | 30A | Additional heater (PTC 1) |
19 | 7.5A | Air conditioning compressor |
20 | 30A | Heated rear windscreen, defrosting system |
21 | 15A | Electric fuel pump in tank |
30 | 15A | Fog lights |
81 | 60A | Additional heater (PTC2) |
82 | 40A | Additional heater (PTC1) |
82 | 50A | Additional heater (PTC2) |
83 | - | Free |
84 | 20A | HI-FI sound system (control units, Bassbox speaker) mechanical gearbox setup |
85 | 15A | Power socket on tunnel |
87 | 7.5A | Electric door mirror demisters, demisters on windscreen jets, relay switch coil for heated windscreen |
Luggage compartment fuse box:
Fuse/Relay N° | Rating | Functions |
1 | 20A | Electric roof opening system |
3 | 15A | Luggage compartment power socket |
6 | 15A | Front seat heater |
