Alfa Romeo MiTo 2013 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located on the driver's side under the instrument panel.
Engine compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 12 | 7.5A | Right dipped beam headlight |
| 13 | 7.5/5A* | Left dipped beam headlight |
| 13 | 7.5A | Headlight alignment adjustment system |
| 32 | 5A | Front roof light, Luggage compartment roof light, Sun visor courtesy light, Door puddle lights, Glove compartment light |
| 36 | 10A | Radio, sound system setup system (for versions/markets, where provided), Uconnect ™ 5" radio (for versions/markets, where provided), climate control system control unit, alarm system control unit, volumetric system control unit, EOBD external diagnosis socket, tyre pressure monitoring control unit |
| 37 | 5A | Instrument panel, brake light on switch |
| 38 | 15A | Door lock motor on doors, Safe Lock motor on doors, Tailgate unlocking motor |
| 43 | 20A | Windscreen/rear window washer pump |
| 47 | 20A | Electric window motor complete with control unit (driver side door) |
| 48 | 20A | Electric window motor complete with control unit (passenger side door) |
| 49 | 5A | Parking sensor control unit, rain/dusk sensor on interior rear view mirror, electrochromic sensor on interior rear view mirror, seat belts fastened warning light display on interior rear view mirror, control panel lighting (central control panel, driver side control panel, control panel on steering wheel), heater pad activation switches on front seats, alarm system volumetric sensor control unit, electric sun roof control unit |
| 51 | 5A | Clutch activation switch, brake light switch, relay switch coils on engine fuse box control unit, control system on internal climate control/heater unit, flow meter, water presence in diesel sensor, radio, radio setup system (for versions/markets, where provided |
| 53 | 5A | Instrument panel |
* Some versions only
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 03 | 20A | Starter |
| 08 | 40A | Passenger compartment electric fan |
| 09 | 5A | Additional heater (Turbo TwinAir 105 HP and 1.3 JTDM-2 85 HP versions) |
| 10 | 15A | Two-tone horns |
| 14 | 15A | Main beam headlights |
| 15 | 30A | Additional heater (PTC 1) |
| 19 | 7.5A | Air conditioning compressor |
| 20 | 30A | Heated rear windscreen, defrosting system |
| 21 | 15A | Electric fuel pump in tank |
| 30 | 15A | Fog lights |
| 81 | 60A | Additional heater (PTC2) |
| 82 | 40A | Additional heater (PTC1) |
| 82 | 50A | Additional heater (PTC2) |
| 83 | - | Free |
| 84 | 20A | HI-FI sound system (control units, Bassbox speaker) mechanical gearbox setup |
| 85 | 15A | Power socket on tunnel |
| 87 | 7.5A | Electric door mirror demisters, demisters on windscreen jets, relay switch coil for heated windscreen |
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 20A | Electric roof opening system |
| 3 | 15A | Luggage compartment power socket |
| 6 | 15A | Front seat heater |
