Alfa Romeo Stelvio 2020 Fuse Box

Alfa Romeo Stelvio 2020 Fuse Box Info



Passenger fuse box location:

The fuse box is located on the right side below the foot board.



Luggage compartment fuse box:



Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
33 25A Front power window (driver’s side)
34 25A Front power window (passenger side)
36 15A Supply for Information and Entertainment system, Climate Control system, alarm, power door mirror folding, EOBD system, USB port
38 20A Safe Lock device (driver side door unlock – if equipped), doors unlock, central lock
43 20A Windshield washer pump
47 25A Rear left power window
48 25A Rear right power window
94 15A Heater rear window coil



Luggage compartment fuse box:

Fuse/Relay N° Rating Functions
01 40A Receiver module (TTM/TTEBM)
08 30A Hi-Fi system
21 10A I-Drive / USB Socket / AUX / USB Charger
22 20A KL15/a 12V Power socket in the luggage compartment
1 20A Trailer light control unit power supply (+30)
2 15A Trailer light control unit power supply (+30)
3 10A Trailer socket (only EMEA) (+30)
4 10A Tow bar (+15)
