Harley-Davidson Pan America 2024 Fuse Box Info
Fuse box location:
The fuse box is located under the riders seat.
Fuse Box Diagram | Layout
Fuse/Relay N° | Rating | Functions |
1 | 10A | Infotainment |
2 | 7.5A | Battery |
3 | 15A | P&A/Battery tender |
The 40A main fuse is located under right steering head cover.
