KTM 200 Duke 2015 Fuse Box

KTM 200 Duke 2015 Fuse Box Info



Fuse box location:

The fuse box is located under the passenger seat.



Fuse Box Diagram | Layout

Fuse/Relay N° Rating Functions
1 30A Main fuse
2 15A Combination instrument
3 10A Control unit, power relay
4 15A Ignition coil, alarm system (Optional)
5 15A Radiator fan
6 15A Horn, brake light, turn signal, high beam, low beam, parking light,
tail light, license plate lamp
