KTM 200 Duke 2014 Fuse Box Info
Fuse box location:
The fuse box is located under the passenger seat.
Fuse Box Diagram | Layout (Without ABS)
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Main fuse |
| 2 | 15A | Combination instrument |
| 3 | 10A | Control unit, power relay |
| 4 | 15A | Ignition coil, alarm system (Optional) |
| 5 | 15A | Radiator fan |
| 6 | 15A | Horn, brake light, turn signal, high beam, low beam, parking light, tail light, license plate lamp |
Fuse Box Diagram | Layout (With ABS)
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Main fuse |
| 2 | 15A | Start auxiliary relay, alarm system (Optional) |
| 3 | 15A | Control unit, power relay |
| 4 | 15A | Ignition coil |
| 5 | 15A | Radiator fan |
| 6 | 15A | Horn, brake light, turn signal, high beam, low beam, parking light, tail light, license plate lamp |
| 7 | 10A | ABS control unit |
| 8 | 10A | Combination instrument, control unit |
| 9 | 10A | Auxiliary equipment |
Two fuses for the ABS are located under the passenger seat. These fuses protect the return pump and the hydraulic unit of the ABS. The third fuse, which protects the ABS control unit, is located in the fuse box.
