Cupra Ateca 2023 Fuse Box

Cupra Ateca 2023 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located at the left side of the steering column at the bottom of the instrument panel behind the cover (Left-hand drive vehicle). The fuse box is located behind the glove box (Right-hand drive vehicle).



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
4 7.5A Alarm horn
5 7.5A Gateway
6 7.5A Automatic gearbox lever
7 10A Air conditioning and heating control panel, back window heating, auxiliary heating
8 7.5A Diagnosis, electronic parking brake switch, light switch, reversing light, interior lighting, driving mode, lit-up door sill, rain sensor
9 7.5A Steering column
10 7.5A Radio display
11 40A Left lights
12 20A Radio
13 25A Driver and passenger seat belt pre-tensioner
14 40A Air conditioner fan
15 10A Steering column release
16 7.5A Connectivity Box
17 7.5A Instrument panel, OCU
18 7.5A Rear camera and surroundings camera
19 7.5A Kessy
20 10/15A SCR, engine relay, 1.5
21 15A 4x4 Haldex Control Unit
22 15A Trailer
23 30A Electric sunroof
24 40A Right lights
25 30A Left door
26 30A Heated seats
27 30A Interior light
28 25A Trailer
31 30A Rear lid control unit
32 7.5/10A Control unit for park distance control, front camera and radar
33 5A Airbag
34 7.5A Reverse switch, climate sensor, electrochromic mirror, rear power sockets (USB)
35 10A Diagnosis, headlight control unit, headlight adjuster
38 25A Trailer
39 30A Right door
40 20A 12V socket
41 25A Driver and passenger seat belt pre-tensioner
42 40A Central locking
43 30A Beats Audio CAN and MOST
44 15A Trailer
45 15A Electric driver's seat
46 7.5A USB socket
47 15A Rear window wiper
49 5A Starter motor; clutch sensor
52 15A Driving mode
53 30A Heated rear window
    In-line fuse
  30A 230V rear power sockets




Engine compartment fuse box:

Fuse/Relay N° Rating Functions
1 25A ESP control unit
2 40/60A ESP control unit
3 15A Engine control unit
4 10A Engine sensors
5 10A Engine sensors
6 7.5A Brake light sensor
7 10A Engine power supply
8 10A Lambda probe
10 30A Pump control unit for T3W Cupra
11 40A PTC
12 40A PTC
13 30A Gearbox pump
14 40A Heated windscreen
15 15A Horn
16 20A Petrol pump
17 7.5A Engine control unit
18 7.5A Terminal 30 (positive reference)
19 30A Front windscreen washer
21 15A Automatic gearbox control unit
22 7.5A Engine control unit
23 30A Starter motor
24 40A PTC
36 15A Left LED headlight
37 20A Parking heating
38 15A Right LED headlight
