Oldsmobile Alero 2001 Fuse Box

Oldsmobile Alero 2001 Fuse Box Info



Passenger compartment fuse box location:

The instrument panel fuse box is located on the end of the instrument panel on the driver’s side.

The instrument panel fuse box is located on the end of the instrument panel on the passenger’s side.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box (Driver’s Side):

Fuse/Relay Functions
Fuses
WIPER Windshield Wiper Motor, Washer Pump
TRUNK REL/ RADIO AMP Trunk Release Relay/Motor, Audio Amplifier
TURN LPS Turn Signal Lamps
PWR MIRROR Power Mirrors
AIR BAG Air Bags
BFC BATT Body Computer (BFC)
PCM ACC PCM
DR LOCK Door Lock Motors
IPC/BFC ACC Cluster, Body Computer (BFC)
STOP LPS Stop Lamps
HAZARD LPS Hazard Lamps
IPC/ HVAC BATT HVAC Head, Cluster, Data Link Connector
Circuit Breaker
PWR SEAT Power Seats
Relays
TRUNK REL Trunk Relay
DR UNLOCK Door Unlock Relay
DR LOCK Door Lock Relay
DRIVER DR UNLOCK Driver’s Door Unlock Relay



Passenger compartment fuse box (Passenger’s Side):

Fuse/Relay Functions
Fuses
INST LPS Interior Lamp Dimming
CRUISE SW LPS Steering Wheel Cruise Control Switch Lamps
CRUISE SW Steering Wheel Cruise Control Switches
HVAC BLOWER HVAC Blower Motor
CRUISE Cruise Control
FOG LPS Fog Lamps
INT LPS Interior Courtesy Lamps
RADIO BATT Radio
SUNROOF Power Sunroof
Circuit Breaker
PWR WNDW Power Windows
Relay
FOG LPS Fog Lamps



Engine compartment fuse box:

Fuse/Relay Functions
Maxi Fuses
1 Ignition Switch
2 Right Electrical Center-Fog Lamps, Radio, Body Function Control Module, Interior Lamps
3 Right Electrical Center-Fog Lamps, Radio, Body Function Control Module, Interior Lamps
4 Anti-Lock Brakes
5 Ignition Switch
6 Not Used
7 Left Electrical Center-Power Seats, Power Mirrors, Door Locks, Trunk Release, Audio Amplifier, Remote Lock Control
8 Cooling Fan #1
Mini Relays
9 Rear Defog
10 Not Used
11 Not Used
12 Cooling Fan #1
13 HVAC Blower (Climate Control)
14 Cooling Fan #2
15 Cooling Fan
Micro Relays
16 Air Conditioning Compressor
17 Not Used
18 Fuel Pump
19 Automatic Light Control
20 Automatic Light Control
21 Horn
22 Daytime Running Lamps
Mini Fuses
23-32 Spare Fuse Holder
33 Rear Defog
34 Accessory Power Outlets, Cigarette Lighter
35 Not Used
36 Not Used
37 Air Conditioning Compressor, Body Function Control Module
38 Automatic Transaxle
39 Powertrain Control Module
40 Anti-Lock Brakes, Variable Effort Steering
41 Ignition System
42 Back-Up Lamps, Brake Transaxle Shift Interlock
43 Horn
44 Powertrain Control Module
45 Parking Lamps
46 Climate Control System, Air Conditioning
47 Canister Vent Valve, Exhaust Oxygen Sensors
48 Fuel Pump, Injectors
49 Generator
50 Right Headlamp
51 Left Headlamp
52 Cooling Fan #2
53 HVAC Blower (Climate Control )
54 Not Used
55 Cooling Fan #2 Ground
56 Fuse Puller for Mini Fuses
57 Not Used
