Volvo S80 2012 Fuse Box Info
Passenger compartment fuse box location:
The fuse boxes A and B in the passenger compartment are located under the glove box.
Engine compartment fuse box location:
Luggage compartment fuse box location:
The rear compartment fuse box is located on the left side of the trunk behind a cover.
Fuse Box Diagram | Layout
Passenger compartment fuse box (Fuse box A):
| Fuse/Relay N° | Rating | Functions |
| 1 | 40A | Circuit breaker for the infotainment system and for fuses 16-20 |
| 2 | - | - |
| 3 | - | - |
| 4 | - | - |
| 5 | - | - |
| 6 | - | - |
| 7 | 15A | 12-volt socket (trunk) |
| 8 | 20A | Controls in driver's door |
| 9 | 20A | Controls in front passenger's door |
| 10 | 20A | Controls in right rear passenger's door |
| 11 | 20A | Controls in left rear passenger's door |
| 12 | 20A | Keyless drive* |
| 13 | 20A | Power driver's seat* |
| 14 | 20A | Power front passenger's seat* |
| 15 | 15A | Folding rear seat head restraints |
| 16 | 5A | Infotainment control module |
| 17 | 10A | Infotainment system, Sirius satellite radio* |
| 18 | 15A | Infotainment system |
| 19 | 5A | Bluetooth hands-free system |
| 20 | 7.5A | Rear Seat Entertainment system (RSE)* |
| 21 | 5A |
Power moonroof* Courtesy lighting, climate system sensor |
| 22 | 15A | 12-volt sockets |
| 23 | 15A | Heated rear seat* (passenger's side) |
| 24 | 15A | Heated rear seat* (driver's side) |
| 25 | - | - |
| 26 | 15A | Heated front passenger's seat* |
| 27 | 15A | Heated driver's seat* |
| 28 | 5A | Park assist*, trailer hitch control module*, park assist camera* |
| 29 | 5A | All Wheel Drive* control module |
| 30 | 10A | Active chassis system* |
* Option/accessory
Passenger compartment fuse box (Fuse box B):
| Fuse/Relay N° | Rating | Functions |
| 1 | - | - |
| 2 | - | - |
| 3 | 7.5A | Front courtesy lighting, driver's door power window controls, power seat(s)*, HomeLInk® Wireless Control System* |
| 4 | 5A | Instrument panel information display |
| 5 | 10A | Adaptive cruise control/ collision warning* |
| 6 | 7.5A | Courtesy lighting, rain sensor* |
| 7 | 7.5A | Steering wheel module |
| 8 | 10A | Cental locking: fuel filler door |
| 9 | - | - |
| 10 | 15A | Windshield washer |
| 11 | 10A | Trunk open |
| 12 | - | - |
| 13 | 20A | Fuel pump |
| 14 | 5A | Climate system control panel |
| 15 | - | - |
| 16 | 5A | Alarm, On-board diagnostic system |
| 17 | - | - |
| 18 | 10A | Airbag system, Occupant weight system |
| 19 | 5A | Collision warning system* |
| 20 | 7.5A | Accelerator pedal, auto-dim mirror function, heated rear seats* |
| 21 | - | - |
| 22 | 5A | Brake lights |
| 23 | 20A | Power moonroof* |
| 24 | 5A | Immobilizer |
* Option/accessory
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 50A | Circuit breaker |
| 2 | 50A | Circuit breaker |
| 3 | 60A | Circuit breaker |
| 4 | 60A | Circuit breaker |
| 5 | 60A | Circuit breaker |
| 6 | - | - |
| 7 | - | - |
| 8 | 20A | Headlight washers* |
| 9 | 30A | Windshield wipers |
| 10 | - | - |
| 11 | 40A | Climate system blower |
| 12 | - | - |
| 13 | 40A | ABS pump |
| 14 | 20A | ABS valves |
| 15 | - | - |
| 16 | 10A | Active Bending Lights-headlight leveling* |
| 17 | 20A | Central electrical module |
| 18 | 5A | ABS |
| 19 | 5A | Speed-dependent steering force* |
| 20 | 10A | Engine Control Module (ECM), transmission, SRS |
| 21 | 10A | Heated washer nozzles* |
| 22 | - | - |
| 23 | 5A | Lighting panel |
| 24 | - | - |
| 25 | - | - |
| 26 | - | - |
| 27 | 5A | Relay - engine compartment box |
| 28 | 20A | Auxiliary lights* |
| 29 | 15A | Horn |
| 30 | 10A | Engine Control Module (ECM) |
| 31 | 15A | Control module - automatic transmission |
| 32 | 15A | A/C compressor |
| 33 | 5A | Relay-coils |
| 34 | 30A | Starter motor relay |
| 35 | 20A | Ignition coils |
| 36 | 10A | Engine Control Module |
| 37 | 15A | Injection system, mass air meter, engine control module |
| 38 | 10A | A/C compressor, engine valves, engine control module |
| 39 | 15A | EVAP valve, heated oxygen sensor |
| 40 | - | - |
| 41 | 5A | Fuel leakage detection |
| 42 | - | - |
| 43 | 80A | Cooling fan |
| 44 | 100A | Electro-hydraulic power steering |
* Option/accessory
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Electric parking brake (left side) |
| 2 | 30A | Electric parking brake (right side) |
| 3 | 30A | Heated rear window |
| 4 | 15A | Trailer socket 2* |
| 5 | - | - |
| 6 | - | - |
| 7 | - | - |
| 8 | - | - |
| 9 | - | - |
| 10 | - | - |
| 11 | 40A | Trailer socket 1* |
| 12 | - | - |
* Option/accessory
