Volvo XC60 2010 Fuse Box

Volvo Hits: 2685

Volvo XC60 2010 Fuse Box Info

Passenger compartment fuse box location:

The fuse box in the passenger compartment is located under the glove box.

Engine compartment fuse box location:

Module A, upper

Module B, front

Module C, lower

Positions: These fuses are all located in the engine compartment box. Fuses in C are located under A.

Luggage compartment fuse box location:

Fuse Box Diagram | Layout

Passenger compartment fuse box:

Fuse/Relay N°	Rating	Functions
1	5A	Rain sensor*
2	10A	SRS system
3	5A	ABS brakes. Electric parking brake
4	7.5A	Accelerator pedal, heated seats*
5	-	-
6	15A	ICM display, CD & Radio
7	7.5A	Steering wheel module
8	-	-
9	15A	High beam
10	20A	Laminated panoramic roof*
11	7.5A	Backup lights
12	-	-
13	15A	Front fog light*
14	15A	Windshield washers
15	10A	Adaptive cruise control ACC*
16	-	-
17	7.5A	Overhead courtesy lighting, Control panel driver's door/ Power passenger seat*
18	5A	Information display
19	5A	Power driver's seat*
20	15A	Tailgate wiper
21	5A	Remote key receiver, Alarm sensors
22	20A	Fuel pump
23	20A	Electric steering column lock
24	-	-
25	10A	Lock, tank/tailgate
26	5A	Alarm siren. ECC
27	5A	START/STOP ENGINE button
28	5A	Brake light switch

* Option/accessory

Engine compartment fuse box:

Fuse/Relay N°	Rating	Functions
1	50A	Circuit breaker
2	50A	Circuit breaker
3	60A	Circuit breaker
4	60A	Circuit breaker
5	50A	Circuit breaker
6	-	-
7	-	-
8	-	-
9	30A	Windshield wipers
10	-	-
11	40A	Climate system blower
12	-	-
13	40A	ABS pump
14	20A	ABS valves
15	-	-
16	10A	Active Bending Lights. Headlight leveling*
17	20A	Central electrical module
18	5A	Radar. ACC control module*
19	5A	Speed-dependent power steering
20	10A	Engine Control Module (ECM), transmission, SRS
21	10A	Heated washer nozzles
22	20A	Vacuum pump I5T
23	5A	Lighting panel
24	15A	Headlight washers
25	15A	12-volt socket, front and rear seat
26	10A	Laminated panoramic roof, ceiling console/ECC
27	5A	Engine compartment box
28	20A	Auxiliary lights*
29	15A	Horn
30	10A	Engine Control Module (ECM)
31	15A	Control module, automatic transmission
32	15A	Compressor A/C
33	5A	Coils
34	30A	Starter motor relay
35	20A	Ignition coils
36	10A	Engine Control Module (ECM), throttle
37	15A	Injection system
38	10A	Engine valves
39	15A	EVAP/heated oxygen sensor/ Injection
40	20A	Crank case ventilation heater
41	5A	Fuel leakage detection
42	-	-
43	-	-
44	80A	Cooling fan

* Option/accessory

Luggage compartment fuse box:

Fuse/Relay N°	Rating	Functions
		Module A (black)
1	25A	Switches in driver's door
2	25A	Switches in passenger's door
3	25A	Switches in rear door, driver's side
4	25A	Switches in rear door, passenger's sid
5	-	-
6	15A	12-V socket in cargo area
7	30A	Rear window defroster
8	-	-
9	15A	Trailer socket 2*
10	25A	Power driver's seat*
11	40A	Trailer socket 1*
12	30A	Power tailgate*
		Module B (white)
1	5A	Park assist, Park assist camera*
2	15A	Control module Four C*
3	15A	Heated driver's seat*
4	15A	Heated passenger's seat*
5	15A	Rear seat heater, passenger's side*
6	10A	AWD control module
7	15A	Rear seat heater, driver's side*
8	-	-
9	25A	Power passenger's seat*
10	20A	Keyless drive*
11	30A	Electric parking brake – driver's side*
12	-	-
		Module D (blue)
1	10A	Navigation system display*
2	-	-
3	25A	Subwoofer*
4	5A	SIRIUS satellite radio*
5	25A	Audio amplifier*
6	15A	Audio system
7	5A	Bluetooth Hands-free system
8	-	Reserve
9	-	Reserve
10	-	Reserve
11	-	Reserve
12	-	Reserve

* Option/accessory
