Smart Fortwo 2008 Fuse Box

Smart Fortwo 2008 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located on the driver’s side below the instrument panel.





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
1 25A Engine
2 25A Windshield wipers
3 20A Power window, left and right
4 25A Blower
5 10A Front fog lamps
6 7.5A Right parking and lamp, instrument lighting, terminal 58R
7 7.5A Parking and lamp, left
8 25A Engine
9 7.5A Engine
10 15A Engine
11 25A ESP®
12 10A Switches strip, on-board diagnosis socket, turn signal lamp, transmission control unit
13 - -
14 15A Charge air cooler, air conditioning compressor
15 15A Audio, subwoofer, interior lighting
16 15A Fuel pump
17 15A Rear window wiper (coupé only)
18 10A ESP®, power steering, air bag, instrument panel
19 7.5A Motor control unit, on-board diagnosis socket, transmission control unit
20 10A Air conditioning system, exterior mirror adjustment, washer pump, audio, seat heating, gear selector lever control unit
