Škoda Yeti 2012 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay N° | Functions |
| 1 |
Heating of the gearbox ventilation (diesel engine) Control unit for automatic gearbox DSG |
| 2 | Towing device |
| 3 | Towing device |
| 4 | Instrument cluster, windshield wiper lever, turn signal light lever, camera |
| 5 | Air blower for heating, radiator fan, air conditioning system, Climatronic |
| 6 | Rear window wiper |
| 7 | Phone |
| 8 | Towing device |
| 9 |
Vehicle voltage control unit - interior lights Rear fog light |
| 10 | Rain sensor, light switch, diagnostic socket |
| 11 | Left side cornering lights |
| 12 | Right side cornering lights |
| 13 | Radio, changer for mobile navigation |
| 14 | Towing device |
| 15 | Light switch |
| 16 | Haldex |
| 17 | Control unit for headlamp beam adjustment and headlight swivel |
| 18 | Diagnostic socket, engine control unit, brake sensor |
| 19 | Control unit for ABS, ESP, switch for tyre air pressure control, control unit for parking aid, switch for OFF ROAD mode, START STOP button |
| 20 | Switch and airbag control unit |
| 21 | WIV, tail light, dimming mirrors, pressure sensor, telephone preinstallation, air mass meter |
| 22 | Instrument cluster, control unit for electromechanical power steering |
| 23 | Central locking system and bonnet lid |
| 24 | Rear power window |
| 25 | Rear window heater, auxiliary heating and ventilation |
| 26 | Power socket in the luggage compartment |
| 27 | Electric sliding/tilting roof, electric sun screen |
| 28 | Fuel pump, injection valves |
| 29 | Front power window |
| 30 | Front and rear lighter |
| 31 | Headlight cleaning system |
| 32 | Front seat heating, regulator for seat heating |
| 33 | Heating, air conditioning, Climatronic, remote control for auxiliary heating |
| 34 | Alarm, spare horn |
| 35 | Control unit for automatic gearbox DSG |
| 36 | DVD |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Not assigned |
| 2 | Control unit for automatic gearbox |
| 3 | Measuring circuit |
| 4 | ABS control unit |
| 5 | Control unit for automatic gearbox |
| 6 | Instrument cluster, windshield wiper lever and turn signal lever |
| 7 | Power suppy terminal 15, Starter |
| 8 | Radio |
| 9 | Phone |
| 10 | Engine control unit |
| 11 | Auxiliary heating and ventilation control unit |
| 12 | Data bus control unit |
| 13 | Engine control unit |
| 14 | Ignition |
| 15 |
Lambda probe, Fuel pump relay Glow plug system |
| 16 | Vehicle voltage control unit, right headlight, right tail light |
| 17 | Horn |
| 18 | Amplifier for digital sound processor |
| 19 | Windscreen wipers |
| 20 | Control valve for fuel pressure |
| 21 | Lambda probe |
| 22 | Clutch pedal switch, brake pedal switch |
| 23 |
Coolant pump Charge pressure control solenoid valve, changeover valve for radiator Fuel high pressure pump |
| 24 | Active charcoal filter, exhaust gas recirculation valve, radiator fan |
| 25 | ABS control unit |
| 26 | Vehicle voltage control unit, left headlight, left tail light |
| 27 | Glow plug system |
| 28 | Windscreen heater |
| 29 | Power supply of the interior |
| 30 | Terminal X |
