Seat Ibiza 2011 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located under the instrument panel behind the cover on the driver’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | Power steering/Engine operation/Flow meter |
| 2 | 10A | Diagnostics/Heater/Autoclimate/Climatronic/Electric anti-dazzle mirror/Navigator/Air conditioning pressure switch/ Climate fan/AFS Control unit/Coming home relay/Soundaktor/CCS |
| 3 | 5A | Petrol engine control unit/Diesel engine control unit/Relay coils/Engine operation/Bi-turbo fuel control unit |
| 4 | 10A | ABS-ESP Control unit/RKA Switch/Gateway control unit/ESP Relay/Rotation sensor |
| 5 | 10A | Reverse light/Heating nozzles |
| 6 | 5A | Instrument panel |
| 7 | 7.5A | Retro fog light/Start-Stop relays |
| 8 | 2A | Paddle levers on steering wheel for automatic gearbox |
| 9 | 10A | Headlight lever/Windscreen wiper switch |
| 10 | 5A | BCM Electronic control unit power supply |
| 11 | 5A | Airbag control unit |
| 12 | 10A | Automatic gearbox/ LPG system |
| 13 | 5A | Exterior mirror control |
| 14 | 15A | Left-hand AFS headlamps |
| 15 | 15A | Right-hand AFS headlamps |
| 16 | - | Vacant |
| 17 | 5A | Number plate light |
| 18 | 7.5A | Clean pump |
| 19 | 5A | Electronic control unit |
| 20 | 15A | Indicators/Brake lights |
| 21 | 5A | Lights control, instrument panel |
| 22 | 5A | Heated mirrors |
| 23 | 7.5A | Engine injection module/ Rain sensor/ Automatic gear lever/ Main petrol relay |
| 24 | 10A | Luggage compartment light, interior light, glove compartment light |
| 25 | 5A | Parking aid |
| 26 | - | Towing hook |
| 27 | 5A | Headlight control |
| 28 | 10A | Lambda probe |
| 29 | 15,20A | Vacuum pump/LPG power supply |
| 30 | 15A | Engine solenoid coils/Additional heating relay/Pressure sensor/AKF Valve |
| 31 | 10A | Petrol engine operation/Glow plugs/Relay coil/Electric fan/Secondary water pump relay |
| 32 | 15,20,30A | Engine control unit |
| 33 | 5A | Clutch switch sensor/Additional heating relay coil/ Servo sensor |
| 34 | 15A | Fuel control unit / Vacuum pump |
| 35 | - | Vacant |
| 36 | 10,15A | Main beam headlight, right |
| 37 | 10,15A | Main beam headlight, left |
| 38 | 30A | Engine heater |
| 39 | - | Vacant |
| 40 | 15A | 12 Volt Input/Cigarette lighter |
| 41 | 25A | Heated seats control unit / Cup Holder |
| 42 | 20A | Horn |
| 43 | 30A | Panorama sunroof |
| 44 | 20A | Windscreen wipers |
| 45 | 30A | Heated rear window |
| 46 | 20A | Radio / Bluetooth / USB + AUX-In / DC-DC converter for Start-Stop |
| 47 | 5A | Climatronic / autoclima / Gateway / Diagnosis /Automatic gearbox (ZSS lock) |
| 48 | 25A | Locking unit |
| 49 | 25A | Electric windows (front) |
| 50 | 30A | Rear electric windows |
| 51 | 25A | Automatic gearbox control unit |
| 52 | 15A | Alarm |
| 53 | 15A | Electro-kinetic pump relay/bi-turbo fuel control unit |
| 54 | 15A | Reverse light for automatic gearbox/ Fog light /Cornering light |
| 55 | 15,20A | Transformer on |
| 56 | 10A | Rear window wiper |
| 57 | 15A | Dipped beam headlights (right side) / Daylight |
| 58 | 15A | Dipped beam headlights (to the left) / Daylight |
Fuses below steering wheel in relay holder:
PTC fuses:
| Fuse/Relay N° | Rating | Functions |
| 1 | 40A | Supplementary electrical heating using air |
| 2 | 40A | Supplementary electrical heating using air |
| 3 | 40A | Supplementary electrical heating using air |
AUX 1 Fuses:
| Fuse/Relay N° | Rating | Functions |
| 1 |
15,20A 20A |
Left daytime light AFS lamp Navigator, Bluetooth, MDI, radio control lever |
| 2 |
15,20A 5A |
Right daytime light AFS lamp Instrument panel / ESP relay |
| 3 | 20A | Headlight washer pump |
AUX 3 Fuses:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Trailer control unit |
| 2 | 20A | Trailer control unit |
| 3 | 20A | Trailer control unit |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Non-metal fuses: | ||
| 1 | 25A | ABS ESP Control unit |
| 2 | 30A | Electroblower climate heater/fan |
| 3 | 30A | Automatic gearbox control unit |
| 4 | 10A | ABS ESP Control unit |
| 5 | 5A | Electronic control unit |
| 6 | 30A | Injection module |
