Seat Leon 2007 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located under the instrument panel behind the cover on the driver’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Diagnosis Switchboard/Instrument lights / Headlights switchboard/ Flowmeter/ Heated wipers |
| 2 | 5A | Engine control unit/ ABS-ESP switchboard/ Automatic gearbox/ Instrument panel/ Trailer switchboard/ Light switch / Brake sensor/ Power steering/ Right and left headlights |
| 3 | 5A | Airbag |
| 4 | 5A | Heating/ Reverse switch/ ASR-ESP switch/ Telephone/ Nozzles/ Electrochrome anti-dazzle mirror/ Tom- tom navigator |
| 5 | 5A | Right xenon headlamp |
| 6 | 5A | Left xenon headlamp |
| 7 | - | Vacant |
| 8 | - | Vacant |
| 9 | - | Vacant |
| 10 | - | Vacant |
| 11 | - | Vacant |
| 12 | 10A | Central locking |
| 13 | 10A | Diagnosis/ Light switch/ Rain sensor |
| 14 | 5A | Automatic gearbox/ Heating/ ESP control unit/ Automatic gearbox lever |
| 15 | 7.5A | Cable control unit |
| 16 | - | Vacant |
| 17 | 5A | Alarm |
| 18 | - | Vacant |
| 19 | - | Vacant |
| 20 | - | Vacant |
| 21 | 10A | Engine management |
| 22 | 40A | Blower control |
| 23 | 30A | Electric windows (front) |
| 24 | - | Vacant |
| 25 | 25A | Rear window heater |
| 26 | 30A | Rear electric windows |
| 27 | 15A | Engine (fuel pump relay/ flowmeter |
| 28 | 25A | Convenience controls |
| 29 | - | Vacant |
| 30 | 20A | Automatic gearbox |
| 31 | 20A | Vacuum pump |
| 32 | - | Vacant |
| 33 | 30A | Sunroof |
| 34 | 25A | Convenience controls |
| 35 | - | Vacant |
| 36 | 20A | Headlight washer system |
| 37 | 30A | Heated seats |
| 38 | 10A | Engine management |
| 39 | - | Vacant |
| 40 | 40A | Blower control |
| 41 | 15A | Rear wiper motor / Switchboard wiring |
| 42 | 15A | 12 V socket/ Cigarette lighter |
| 43 | 15A | Trailer bracket preinstallation |
| 44 | 20A | Trailer bracket preinstallation |
| 45 | 15A | Trailer bracket preinstallation |
| 46 | - | Vacant |
| 47 | 10A | Engine management |
| 48 | 10A | Engine management |
| 49 | - | Vacant |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Left part | ||
| 1 | 30A | Clean |
| 2 | 5A | Steering column |
| 3 | 5A | Cable control unit |
| 4 | 10A | ABS |
| 5 | 15A | AQ gearbox |
| 6 | 5A | Instrument panel |
| 7 | - | Vacant |
| 8 | 15A | Radio |
| 9 | 5A | Telephone/TomTom Navigator |
| 10 |
5A 10A |
Engine management Engine management |
| 11 | - | Vacant |
| 12 | 5A | Gateway |
| 13 |
25A 30A |
Petrol injection module supply Diesel injection module supply |
| 14 | 20A | Coil |
| 15 |
5A 10A |
Engine management Fuel pump relay |
| 16 | 30A | ABS pump |
| 17 | 15A | Horn |
| 18 | - | Vacant |
| 19 | 30A | Clean |
| 20 | - | Vacant |
| 21 | 15A | Lambda probe |
| 22 | 5A | Brake pedal, speed sensor |
| 23 |
5A 10A 15A |
Engine management Engine management Engine management |
| 24 | 10A | ARF, change valve |
| 25 | 40A | Right lighting |
| 26 | 40A | Left lighting |
| 27 |
40A 50A |
Engine management Engine management |
| 28 | 40A | Ignition key |
| 29 |
50A 30A |
Electric windows (front and back) Electric windows (front) |
| 30 | 40A | Ignition key |
| Side box | ||
| B1 |
150A 200A |
Alternator < 140 W Alternator > 140 W |
| C1 | 80A | Power steering servo |
| D1 | 100A | Multi-terminal voltage supply “30”. Internal fuse box |
| E1 | 50/80A | Ventilator < 500 W / Ventilator > 500 W |
| F1 | 100A | PTCs (Supplementary electrical heating using air) |
| G1 | 50A | Trailer fuse voltage supply in internal fuse box |
| H1 | - | Central locking control unit |
