Peugeot 607 2006 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel, behind the cover.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Front wash-wipe pump and wash-wipe fluid level sensor |
| 2 | 30A | Locking and deadlocking earth |
| 3 | 5A | Air bags |
| 4 | 10A | Clutch switch, brake dual-function switch, diagnostic connector, ESP sensor, air bags and pre-tensioners unit, air conditioning BCP3 relay, electrochromatic mirror |
| 5 | 30A | Front electric windows and sunroof supply |
| 6 | 30A | Rear electric windows supply |
| 7 | 5A | Glove box switch, courtesy lights, map reading lights, courtesy mirrors |
| 8 | 20A | Multifunction display supply, steering wheel control, alarm siren, trailer fusebox supply |
| 9 | 30A | Front and rear lighters (100 W max.) |
| 10 | 15A | Additive reservoir control unit supply |
| 11 | 15A | Automatic gearbox control unit, automatic gearbox positions selection switch, ignition switch |
| 12 | 15A | Trailer fusebox supply, hands-free kit, seats relay, seat memory unit, rain and brightness sensor |
| 13 | 5A | Engine fusebox supply, headlamp adjustment supply |
| 14 | 15A | Parking assistance control unit supply, headlamp adjustment switch, instrument panel, air conditioning, air bags and pretensioners unit |
| 15 | 30A | Locking and deadlocking supply |
| 17 | 40A | Heated rear screen and heated mirrors |
| 31 | 5A | Right-hand brake light |
| 32 | 5A | Left-hand brake light |
| 33 | 5A | Third brake light |
| 34 | 5A | Audio/telephone supply |
| 35 | 5A | Tyre under-inflation detection control unit, CD changer |
| 36 | 30A | Passenger seat relay |
| 37 | 30A | Passenger and rear right heated seats |
| 38 | 30A | Driver's and rear left heated seats |
| 39 | 30A | Driver's seat relay |
| 40 | 5A | Diagnostics socket |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 20A | Fan assembly relay control, additional fan assembly (2.7 litre V6 HDI 24V), engine control unit power relay |
| 2 | 15A | Horn |
| 3 | 10A | Front and rear wash-wipe |
| 4 | 20A | Headlamp wash |
| 5 | 15A | Fuel pump and purge canister solenoid valve |
| 6 | 10A | Power steering, suspension control unit, automatic gearbox |
| 7 | 10A | Engine control unit, ESP control unit |
| 8 | 15A | Starter coil |
| 9 | 10A | Level sensor, passenger compartment heating (HDI), STOP switch |
| 10 | 30A | Engine management actuators (ignition coil, solenoid valves, oxygen sensors, control units, injectors) |
| 11 | 40A | Air conditioning blower relay |
| 12 | 30A | Windscreen wipers relay |
| 13 | 40A | Built-in system interface supply (ignition positive) |
| 14 | 30A | Air pump (petrol) |
