Peugeot 607 2003 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel, behind the cover.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay N° | Rating | Functions |
| R | - | Replacement fuses |
| 1 | 30A | Locking / deadlocking |
| 2 | 20A | Radio amplifier |
| 3 | 30A | Windscreen wash |
| 4 | 30A | Rear window switches on rear doors |
| 5 | 15A | Electronic immobiliser, monochrome screen or colour screen control unit, instrument panel, air conditioning control unit, audio system / telephone |
| 6 | 10A | Rear right brake light |
| 7 | 10A | Switches, rear lighter illumination, front courtesy light, rear courtesy light, rear lighter, number plate lighting, headlamp height adjustment |
| 8 | 10A | Diagnostic connector, headlamp height adjustment control unit, HF locking receiver, passenger compartment air temperature sensor, HF tyre under-inflation receiver |
| 9 | 20A | Headlamp wash |
| 10 | 20A | Glove box lighting, front lighter, front and rear courtesy light, electrochrome interior mirror, electric exterior mirrors |
| 11 | 5A | Control unit for automatic lighting of headlamps, air bags control unit, safety relay for automatic lighting of headlamps |
| 12 | 30A | Rear window switches on driver's pad, rear windows |
| 13 | 30A | Windscreen wiper |
| 14 | 15A | Not used |
| 15 | 15A | Driver's door pad, passenger's door pad |
| 16 | 15A | Rear lighter |
| 17 | 5A | Heated exterior mirrors |
| 18 | 15A | Rear left brake light, additional brake light |
| 19 | 10A | Parking assistance control unit, navigation control unit |
| 20 | 15A | Alarm siren, monochrome screen or colour screen control unit, HF receiver, audio system / telephone, monochrome or colour navigation control unit, diesel additive control unit |
| 21 | 15A | Dignostic connector, caravan socket, trailer sidelights relay |
| 22 | 15A | Diesel additive control unit, driver's seat memory control unit, driver's door pad, passenger's door pad |
| 23 | 30A | Driver's window, passenger's window, sunroof safety auto-reverse, passenger window switch on driver's door pad andpassenger's door pad |
| 24 | 10A | Rear fog lamp |
| 25 | 40A | PARC shunt |
| 26 | 40A | Heated rear screen, radio aerial amplifier |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 70A | Built-in systems interface ( heated rear screen - heated exterior mirrors - windscreen wiper - screenwash - headlamp wash) |
| 2 | 50A | Fan |
| 3 | 50/60A | ESP pump motor / ABS hydraulic unit |
| 4 | 40A | Air conditioning blower |
| 5 | 20A | Horn - Horn control relay |
| 6 | 20A | Left front and rear heated seats |
| 7 | 20A | Right front and rear heated seats |
| 8 | 70A | Built-in systems interface |
| 9 | 30A | Passenger electric seat |
| 10 | 20A | Automatic headlamp lighting control unit |
| 11 | 70A | Built-in systems interface |
| 12 | 70A | Ignition supply (+ve accessories / ignition controlled +ve) |
| 13 | 20A | Automatic headlamp lighting control unit |
| 14 | 15A | Double injection relay supply |
| 15 | - | Not used |
| 16 | - | Not used |
| 17 | 30A | ESP hydraulic unit |
| 18 | 30A | Ignition supply (+ starter) |
| 19 | 20A | Variable suspension control unit |
| 20 | 10A | Fan unit relay - Cruise control safety switch - Manual gearbox clutch switch - Manual gearbox reversing lights switch or automatic gearbox multi-function switch - Automatic headlamp lighting control unit - Vehicle speed sensor - Coolant level sensor - Water in diesel sensor - Power switch control unit relay |
| 21 | 5A | Automatic gearbox control unit - Automatic gearbox multi-function switch |
| 22 | 25A | ESP control unit |
| 23 | 15A | Diesel heating |
| 24 | 5A | Engine management control unit – Dual control control unit |
| 25 | 10A | Fuel pump |
| 26 | 30A | Driver's seat memory control unit |
| 27 | 25A | Double injection relay supply |
| 28 | 10A | Throttle housing de-icing resistor, Intake pilot solenoid valve - Flow meter - Piston de-activator injectionpump - Oil heating |
| 29 | 30A | Air pump, diesel additive control unit - Diesel additive injector |
| 30 | - | Cannot be used |
| 31 | 5A | Automatic gearbox shift lock |
| 32 | 10A | ESP or ABS control unit |
| 33 | 15A | Automatic gearbox control unit - Automatic gearbox multi-function switch (except reversing lights) - Automatic gearbox sequential control |
| 34 | 5A | Oxygen sensors - Exhaust gas recirculation solenoid valve, Exhaust gas recirculation throttle solenoid valve - Turbo pressure regulation solenoid valve |
