Peugeot 4007 2008 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located in the lower part of the fascia behind the enclosed storage compartment.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Heating |
| 2 | 15A | Brake lights, third brake light, built-in systems interface |
| 3 | 10A | Rear fog lamps |
| 4 | 30A | Windscreen wipers and wash-wipe |
| 5 | 10A | Diagnostic socket |
| 6 | 20A | Central locking, exterior mirrors |
| 7 | 15A | Audio equipment, telematics, multifunction display, hands-free kit, rear DVD player |
| 8 | 7.5A | Remote control key, air conditioning control unit, instrument panel, controls bar, steering wheel controls |
| 9 | 15A | Multifunction display, instrument panel |
| 10 | 15A | Built-in systems interface |
| 11 | 15A | Rear wiper |
| 12 | 7.5A | Instrument panel, 4 wheel drive control unit, air conditioning control panel, ABS control unit, multifunction display, automatic headlamp adjustment, heated seats, air bags control unit, steering wheel angle sensor, sunroof, rear screen demisting, remote control |
| 13 | - | Not used |
| 14 | 10A | Ignition switch |
| 15 | 20A | Sunroof |
| 16 | 10A | Exterior mirrors, audio equipment, telematics, rear DVD player |
| 17 | 10A | 4 wheel drive control unit |
| 18 | 7.5A | Reversing lights, parking assistance control unit, reversing camera, air bags control unit |
| 19 | 15A | Accessories socket |
| 20 | 30A | Electric window controls |
| 21 | 30A | Rear screen demisting |
| 22 | 7.5A | Heated exterior mirrors |
| 23 | - | Not used |
| 24 | 25A | Driver's electric seat, footwell lighting, releasing of the rear bench seat |
| 25 | 30A | Heated seats |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Front fog lamps |
| 2 | 7A | Engine ECU 2.4 litre 16V |
| 3 | 20A | CVT automatic gearbox ECU, relay CVT automatic gearbox ECU |
| 4 | 10A | Horn |
| 5 | 7.5A | Alternator 2.4 litre 16V |
| 6 | 20A | Headlamp wash |
| 7 | 10A | Air conditioning |
| 8 | 15A | Engine ECU 2.4 litre 16V |
| 9 | - | Not used |
| 10 | 15A | Demisting, wipers |
| 11 | - | Not used |
| 12 | - | Not used |
| 13 | - | Not used |
| 14 | 10A | Left-hand main beam headlamp |
| 15 | 10A | Right-hand main beam headlamp |
| 16 | 20A | Left-hand dipped headlamp (xenon) |
| 17 | 20A | Right-hand dipped headlamp (xenon) |
| 18 | 10A | Left-hand dipped headlamp, manual and automatic headlamp adjustment |
| 19 | 10A | Right-hand dipped headlamp |
| 20 | - | Not used |
| 21 | - | Not used |
| 22 | 20A | Engine control unit, water in diesel detector, injection pump (Diesel), air flow sensor |
| 23 | 15A | Petrol pump, fuel gauge |
| 24 | 30A | Starter |
| 25 | - | Not used |
| 26 | 40A | ABS control unit, ASC control unit |
| 27 | 30A | ABS control unit, ASC control unit |
| 28 | 30A | Condenser fan |
| 29 | 40A | Radiator fan |
| 30 | 30A | Passenger compartment fuse box |
| 31 | 30A | Audio amplifier |
| 32 | 30A | Engine control unit |
| 33 | 10A | Spare |
| 34 | 15A | Spare |
| 35 | 20A | Spare |
