Peugeot 207 2005 Fuse Box Diagram
Fuse box location:
The fusebox is located below the dashboard.
Engine compartment fusebox:
The fusebox is placed in the engine compartment near the battery.
Fuse Box Diagram | Layout
Dashboard fuses:
Fuse N° | Rating | Functions |
F1 | 15 A | Rear wiper. |
F2 | - | Not used. |
F3 | 5 A | Air bags and pre-tensioners control unit. |
F4 | 10 A | Clutch pedal switch, diagnostic socket, electrochromatic interior mirror, air conditioning, steering wheel angle sensor, particle emission filter pump (Diesel). |
F5 | 30 A | Electric windows, rear electric windows, sunroof. |
F6 | 30 A | Front electric windows, folding mirrors supply. |
F7 | 5 A | Front and rear courtesy lights, map reading lights, sun visor lighting, glove box lighting, clock. |
F8 | 20 A | Audio equipment, audio/telephone, CD changer, multifunction display, clock, steering wheel controls, tyre under-inflation detection, trailer fuse box. |
F9 | 30 A | Front 12 V socket. |
F10 | 15 A | Alarm siren, alarm control unit, directional headlamps. |
F11 | 15 A | Diagnostic socket, low current ignition switch. |
F12 | 15 A | Rain/brightness sensor, amplifier, trailer fuse box, driving school module. |
F13 | 5 A | Engine fuse box, ABS relay, "2 Tronic" gearbox selector lever, dual-function brake switch. |
F14 | 15 A | Instrument panel, seat belt warning lights bar, headlamp adjustment, air conditioning, hands-free kit, rear parking assistance control unit, air bags. |
F15 | 30 A | Locking and deadlocking. |
F17 | 40 A | Rear screen and exterior mirrors de-icing. |
SH | - | PARC shunt. |
Fuse N° | Rating | Functions |
G39 | 20 A | Hi-Fi amplifier. |
G40 | - | Not used |
Engine compartment fusebox:
Fuse N° | Rating | Functions |
F1 | 20 A | Engine control unit and fan assembly control relay supply, air flow sensor (Diesel), injection pump (Diesel), water in diesel sensor (Diesel), EGR solenoid valves, air heating (Diesel). |
F2 | 15 A | Horn. |
F3 | 10 A | Front and rear wash-wipe. |
F4 | 20 A | Headlamp wash. |
F5 | 15 A | Fuel pump (petrol). |
F6 | 10 A | Vehicle speed sensor. |
F7 | 10 A | Electric power steering, directional headlamps, directional headlamps control relay, engine coolant level detector (Diesel), switching and protection unit (Diesel). |
F8 | 20 A | Starter control. |
F9 | 10 A | ABS/ESP control unit, brake pedal switch. |
F10 | 30 A | Engine control unit actuators (petrol: ignition coils, solenoid valves, oxygen sensors, injectors, heaters, controlled thermostat) (diesel solenoid valves, heaters). |
F11 | 40 A | Air conditioning blower. |
F12 | 30 A | Windscreen wipers Low/High speed. |
F13 | 40 A | Built-in systems interface supply (ignition positive). |
F14 | 30 A | Diesel heater (Diesel). |
F15 | 10 A | Left main beam headlamp. |
F16 | 10 A | Right main beam headlamp. |
F17 | 15 A | Left dipped beam headlamp. |
F18 | 15 A | Right dipped beam headlamp. |
Maxi fuses:
Fuse N° | Rating | Functions |
MF1 | 70 A | Fan assembly. |
MF2 | 20 A/30 A | ABS/ESP pump. |
MF3 | 20 A/30 A | ABS/ESP solenoid valves. |
MF4 | 60 A | Built-in systems interface supply. |
MF5 | 60 A | Built-in systems interface supply. |
MF6 | - | Not used. |
MF7 | 80 A | Passenger compartment fuse box. |
MF8 | 30 A | "2 Tronic" gearbox control unit. |
MF9 | 80 A | Heating unit (Diesel). |
MF10 | 80 A | Electric power steering. |
