Lincoln MKZ 2016 Fuse Box Info
Fuse box location:
The fuse box is under the instrument panel to the left of the steering column.
Engine compartment fuse box:
The power distribution box is located in the engine compartment. It has high-current fuses that protect your vehicle's main electrical systems from overloads. There are fuses located on the bottom of the fuse box.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Lighting (ambient, glovebox, vanity, dome, trunk) |
| 2 | 7.5A | Memory seats, Lumbar, Power mirror |
| 3 | 20A | Driver door unlock |
| 4 | 5A | Not used (spare) |
| 5 | 20A | Subwoofer amplifier |
| 6 | 10A | Heated seat relay coil |
| 7 | 10A | Not used (spare) |
| 8 | 10A | Not used (spare) |
| 9 | 10A | Not used (spare) |
| 10 | 5A | Power trunk logic, Keypad, Cellphone passport module |
| 11 | 5A | Not used (spare) |
| 12 | 7.5A | Climate control, Gear shift |
| 13 | 7.5A | Steering wheel column, Cluster, Datalink logic |
| 14 | 10A | Battery electronic control module |
| 15 | 10A | Datalink/Gateway module |
| 16 | 15A | Trunk release, Child lock |
| 17 | 5A | Tracking and blocking |
| 18 | 5A | Ignition, Push button stop/start |
| 19 | 7.5A | Passenger airbag disabled indicator, Transmission range |
| 20 | 7.5A | Adaptive headlamps |
| 21 | 5A | Humidity and in-car temperature sensor |
| 22 | 5A | Occupant classification sensor |
| 23 | 10A | Delayed accessory (power inverter, smart window, driver window switch) |
| 24 | 20A | Central lock/unlock |
| 25 | 30A | Driver's door (window, mirror) |
| 26 | 30A | Front passenger's door (window, mirror) |
| 27 | 30A | Moonroof |
| 28 | 20A | Amplifier |
| 29 | 30A | Rear driver's side door (window) |
| 30 | 30A | Rear passenger's side door (window) |
| 31 | 15A | Not used (spare) |
| 32 | 10A | GPS, Voice control, Display, Adaptive cruise control, Radio frequency receiver |
| 33 | 20A | Radio, Active noise control, CD changer |
| 34 | 30A | Run/start bus (fuse #19, 20, 21, 22, 35, 36, 37, circuit breaker) |
| 35 | 5A | Restraints control module |
| 36 | 15A | Continuous control damping suspension module, Auto dimming rear view mirror, Rear heated seats |
| 37 | 15A | Heated steering wheel, All wheel drive |
| 38 | 30A | Not used (spare) |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Wide open panoramic roof 1 |
| 2 | - | Starter relay |
| 3 | 15A | Rain sensor |
| 4 | - | Blower motor relay |
| 5 | 20A | Power point 3 - Back of console |
| 6 | - | Not used |
| 7 | 20A | Powertrain control module - vehicle power 1 |
| 8 | 20A | Powertrain control module - vehicle power 2 |
| 9 | - | Powertrain control module relay |
| 10 | 20A | Power point 1 - driver front |
| 11 | 15A | Powertrain control module - vehicle power 4 |
| 12 | 15A | Powertrain control module - vehicle power 3 |
| 13 | 10A | Powertrain control module - vehicle power 5 |
| 14 | 10A | Powertrain control module - vehicle power 6 |
| 15 | - | Run/start relay |
| 16 | 20A | Power point 2 - console |
| 17 | - | Not used |
| 18 | - | Not used |
| 19 | 10A | Run/start electronic power assist steering |
| 20 | 10A | Run/start lighting |
| 21 | 15A | Run/start transmission control, Transmission oil pump start/stop |
| 22 | 10A | Air conditioner clutch solenoid |
| 23 | 15A | Run/start: Blind spot information system, Rear view camera, Adaptive cruise control, Heads-up display, Shifter, Voltage stability module |
| 24 | - | Not used |
| 25 | 10A | Run/start anti-lock brake system |
| 26 | 10A | Run/start powertrain control module |
| 27 | - | Not used |
| 28 | - | Not used |
| 29 | 5A | Mass air flow monitor |
| 30 | - | Not used |
| 31 | - | Not used |
| 32 | - | Electronic fan #1 relay |
| 33 | - | Air conditioner clutch relay |
| 34 | - | Not used |
| 35 | - | Not used |
| 36 | - | Not used |
| 37 | - | Not used |
| 38 | - | Electronic fan 2 relay |
| 39 | - | Electronic fan coil 2 and 3 relay |
| 40 | - | Horn relay |
| 41 | - | Not used |
| 42 | - | Fuel pump relay coil |
| 43 | - | Not used |
| 44 | - | Not used |
| 45 | - | Not used |
| 46 | - | Not used |
| 47 | - | Not used |
| 48 | - | Not used |
| 49 | 10A | Keep-alive power |
| 50 | 20A | Horn |
| 51 | - | Not used |
| 52 | - | Not used |
| 53 | 10A | Power seats |
| 54 | 10A | Brake on-off switch |
| 55 | 10A | Alt sensor |
Engine compartment fuse box - bottom:
There are fuses located on the bottom of the fuse box. To access the bottom of the fuse box, do the following:
1. Release the two latches, located on both sides of the fuse box.
2. Raise the inboard side of the fuse box from the cradle.
3. Move the fuse box toward the center of the engine compartment.
4. Pivot the outboard side of the fuse box to access the bottom side.
| Fuse/Relay N° | Rating | Functions |
| 56 | - | Not used |
| 57 | 20A | Diesel vaporizer or E100 |
| 58 | 30A | Fuel pump feed |
| 59 | 30A | Electronic fan 3 |
| 60 | 30A | Electronic fan 1 |
| 61 | - | Not used |
| 62 | 50A | Body control module 1 |
| 63 | 25A | Electronic fan 2 |
| 64 | - | Not used |
| 65 | 20A | Front heated seat |
| 66 | - | Not used |
| 67 | 50A | Body control module 2 |
| 68 | 40A | Heated rear window |
| 69 | 30A | Anti-lock brake system valves |
| 70 | 30A | Passenger seat |
| 71 | - | Not used |
| 72 | 20A | Transmission oil pump |
| 73 | 20A | Rear climate controlled seats |
| 74 | 30A | Driver seat module |
| 75 | 25A | Wiper motor 1 |
| 76 | 30A | Power lift gate module |
| 77 | 30A | Front climate controlled seats |
| 78 | 40A | Trailer tow module |
| 79 | 40A | Blower motor |
| 80 | 25A | Wiper motor 2 |
| 81 | 40A | Inverter |
| 82 | - | Not used |
| 83 | 20A | TRCM shifter |
| 84 | 30A | Starter solenoid |
| 85 | 30A | Wide open panoramic roof 2 |
| 86 | - | Not used |
| 87 | 60A | Anti-lock brake system pump |
