Lincoln MKZ 2015 Fuse Box Info
Fuse box location:
The fuse box is under the instrument panel to the left of the steering column.
Engine compartment fuse box:
The power distribution box is located in the engine compartment. It has high-current fuses that protect your vehicle's main electrical systems from overloads. There are fuses located on the bottom of the fuse box.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Lighting (ambient, glovebox, vanity, dome, trunk) |
| 2 | 7.5A | Memory seats, Lumbar, Power mirror |
| 3 | 20A | Driver door unlock |
| 4 | 5A | Not used (spare) |
| 5 | 20A | Subwoofer amplifier, THX amplifier |
| 6 | 10A | Heated seat relay coil |
| 7 | 10A | Not used (spare) |
| 8 | 10A | Not used (spare) |
| 9 | 10A | Not used (spare) |
| 10 | 5A | Power trunk logic, Keypad |
| 11 | 5A | Not used (spare) |
| 12 | 7.5A | Climate control, Gear shift |
| 13 | 7.5A | Steering wheel column, Cluster, Datalink logic |
| 14 | 10A | Not used (spare) |
| 15 | 10A | Datalink/Gateway module |
| 16 | 15A | Trunk release, Child lock |
| 17 | 5A | Not used (spare) |
| 18 | 5A | Ignition, Push button stop/start |
| 19 | 5A | Passenger airbag disabled indicator, Transmission range |
| 20 | 5A | Adaptive headlamps |
| 21 | 5A | Humidity and in-car temperaturesensor, Blind-spot information system, Rear video camera, Adaptive cruise control |
| 22 | 5A | Occupant classification sensor |
| 23 | 10A | Delayed accessory (power inverter, smart window, driver window switch) |
| 24 | 20A | Central lock/unlock |
| 25 | 30A | Driver's door (window, mirror) |
| 26 | 30A | Front passenger's door (window, mirror) |
| 27 | 30A | Moonroof |
| 28 | 20A | THX amplifier |
| 29 | 30A | Rear driver's side door (window) |
| 30 | 30A | Rear passenger's side door (window) |
| 31 | 15A | Not used (spare) |
| 32 | 10A | GPS, Voice control, Display, Adaptive cruise control, Radio frequency receiver |
| 33 | 20A | Radio, Active noise control |
| 34 | 30A | Run/start bus (fuse #19, 20, 21, 22, 35, 36, 37, circuit breaker) |
| 35 | 5A | Restraints control module |
| 36 | 15A | Continuous control damping suspension, Auto-dimming rear view mirror, Lane keeping system module, Auto high beam, All wheel drive module |
| 37 | 15A | Heated steering wheel, Voltage stability module logic power |
| 38 | 30A | Rear window shade |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Moonroof |
| 2 | - | Starter relay |
| 3 | 15A | Autowipers |
| 4 | - | Blower motor relay |
| 5 | 20A | Power point 3 - Back of console |
| 6 | - | Not used |
| 7 | 20A | Powertrain control module - vehicle power 1 |
| 8 | 20A | Powertrain control module - vehicle power 2 |
| 9 | - | Powertrain control module relay |
| 10 | 20A | Power point 1 - driver front |
| 11 | 15A | Powertrain control module - vehicle power 4 |
| 12 | 15A | Powertrain control module - vehicle power 3 |
| 13 | 10A | Powertrain control module - vehicle power 5 |
| 14 | 10A | Powertrain control module - vehicle power 6 |
| 15 | - | Run/start relay |
| 16 | 20A | Power point 2 - console |
| 17 | 20A | Not used (spare) |
| 18 | 10A | Powertrain control module - keep alive power |
| 19 | 10A | Run/start electronic power assist steering |
| 20 | 10A | Run/start lighting |
| 21 | 15A | Run/start transmission control, Transmission oil pump start/stop |
| 22 | 10A | Air conditioner clutch solenoid |
| 23 | 15A | Run/start: Blind spot information system, Rear view camera, Adaptive cruise control, Heads-up display, Shifter |
| 24 | 10A | Run-start 7 |
| 25 | 10A | Run/start anti-lock brake system |
| 26 | 10A | Run/start powertrain control module |
| 27 | - | Not used |
| 28 | - | Not used |
| 29 | 5A | Mass air flow monitor |
| 30 | - | Not used |
| 31 | - | Not used |
| 32 | - | Electronic fan #1 relay |
| 33 | - | Air conditioner clutch relay |
| 34 | - | Not used |
| 35 | - | Not used |
| 36 | - | Not used |
| 37 | - | Not used |
| 38 | - | Electronic fan 2 relay |
| 39 | - | Not used |
| 40 | - | Electronic fan 2 relay coil, Electronic fan 3 relay coil |
| 41 | - | Horn relay |
| 42 | - | Fuel pump relay coil |
| 43 | - | Not used |
| 44 | - | Not used |
| 45 | - | Not used |
| 46 | - | Not used |
| 47 | - | Not used |
| 48 | - | Not used |
| 49 | 10A | Keep-alive power |
| 50 | 20A | Horn |
| 51 | - | Not used |
| 52 | - | Not used |
| 53 | 10A | Power seats |
| 54 | 10A | Brake on-off switch |
| 55 | 10A | Alt sensor |
Engine compartment fuse box - bottom:
There are fuses located on the bottom of the fuse box. To access the bottom of the fuse box, do the following:
1. Release the two latches, located on both sides of the fuse box.
2. Raise the inboard side of the fuse box from the cradle.
3. Move the fuse box toward the center of the engine compartment.
4. Pivot the outboard side of the fuse box to access the bottom side.
| Fuse/Relay N° | Rating | Functions |
| 56 | - | Not used |
| 57 | 30A | Diesel vaporizer or E100 |
| 58 | 30A | Fuel pump feed |
| 59 | 30A | 500W Electronic fan 3 |
| 60 | 30A | 500W Electronic fan 1 |
| 61 | - | Not used |
| 62 | 50A | Body control module 1 |
| 63 | 20A | 500W Electronic fan 2 |
| 64 | - | Not used |
| 65 | 20A | Front heated seat |
| 66 | - | Not used |
| 67 | 50A | Body control module 2 |
| 68 | 40A | Heated rear window |
| 69 | 30A | Anti-lock brake system valves |
| 70 | 30A | Passenger seat |
| 71 | - | Not used |
| 72 | 20A | Transmission oil pump |
| 73 | 20A | Rear climate controlled seats |
| 74 | 30A | Driver seat module |
| 75 | 25A | Wiper motor 1 |
| 76 | 20A | Transmission oil pump 2 stop/start |
| 77 | 30A | Front climate controlled seats |
| 78 | 40A | Trailer tow module |
| 79 | 40A | Blower motor |
| 80 | 30A | Power trunk |
| 81 | 40A | Inverter |
| 82 | - | Not used |
| 83 | 25A | Wiper motor #1 |
| 84 | 30A | Starter solenoid |
| 85 | 30A | Moonroof 2 |
