Lincoln MKX 2016 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located under the instrument panel to the left of the steering column.
Engine compartment fuse box location:
The power distribution box is located in the engine compartment. It has high-current fuses that protect your vehicle's main electrical systems from overloads. There are fuses located on the bottom of the fuse box.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay N° | Rating | Functions |
1 | 10A | Demand lighting (glove box, vanity, dome), Battery saver relay coil, Second row easy fold relay coil |
2 | 7.5A | Memory seats, Lumbar, Power mirrors, Driver seat module logic power |
3 | 20A | Driver door unlock |
4 | 5A | Not used (spare) |
5 | 20A | Subwoofer amplifier |
6 | 10A | USB charger |
7 | 10A | Not used (spare) |
8 | 10A | Not used (spare) |
9 | 10A | Rear seat entertainment system module, 360 camera badge |
10 | 5A | Keypad, Power liftgate module logic power, Hands free liftgate module, MyLincoln module |
11 | 5A | Not used (spare) |
12 | 7.5A | Climate control module |
13 | 7.5A | Cluster, Steering column control module, Smart datalink connector (gateway) module |
14 | 10A | Not used (spare) |
15 | 10A | Datalink power |
16 | 15A | Not used (spare) |
17 | 5A | Not used (spare) |
18 | 5A | Ignition switch, Push button start switch, Key inhibit solenoid |
19 | 7.5A | Not used (spare) |
20 | 7.5A | Active front steering logic power |
21 | 5A | Humidity and in-car temperature sensor |
22 | 5A | Occupant classification sensor |
23 | 10A | Delayed accessory (power inverter logic, moonroof logic, driver window switch power), Heads up display, Gear shift module, Front camera, 360 camera module |
24 | 20A | Central lock unlock |
25 | 30A | Driver door (window, mirror), Driver door module, Driver door lock indicator, Driver lock switch illumination |
26 | 30A | Front passenger door (window, mirror), Front passenger door module, Front passenger lock indicator, Front passenger switch illumination (window, lock) |
27 | 30A | Moonroof |
28 | 20A | Amplifier |
29 | 30A | Rear driver side door smart window |
30 | 30A | Rear passenger side door smart window |
31 | 15A | Not used (spare) |
32 | 10A | Global positioning system module, Centerstack display, Voice control (SYNC), Radio transceiver module, Multimedia gateway module |
33 | 20A | Radio |
34 | 30A | Run-start bus (fuse 19, 20, 21, 22, 35, 36, 37, circuit breaker 38) |
35 | 5A | Restraints control module |
36 | 15A | Auto-dimming rear view mirror, Heated seat, Auto high beam/lane departure mirror module, Rear heated seat module logic power, Suspension module |
37 | 20A | Heated steering wheel module (without active front steering) |
38 | 30A | Rear power windows, Rear window switch illumination |
Engine compartment fuse box:
Fuse/Relay N° | Rating | Functions |
1 | 30A | Power fold 2nd row seats |
2 | - | Starter relay |
3 | 15A | Rear wiper, Rain sensor |
4 | - | Blower motor relay |
5 | 20A | Power point 3 - Back of console |
6 | - | Not used |
7 | 20A | Powertrain control module - vehicle power 1 |
8 | 20A | Powertrain control module - vehicle power 2 |
9 | - | Powertrain control module relay |
10 | 20A | Power point 1 - driver front |
11 | 15A | Powertrain control module - vehicle power 4 |
12 | 15A | Powertrain control module - vehicle power 3 |
13 | - | Not used |
14 | - | Not used |
15 | - | Run/start relay |
16 | 20A | Power point 2 - console bin |
17 | 20A | Power point 4 - luggage compartment |
18 | 20A | RH HID headlamp |
19 | 10A | Run/start electronic power assist steering |
20 | 10A | Run/start lighting |
21 | 15A | Transmission oil pump logic power (start/stop) |
22 | 10A | Air conditioner clutch solenoid |
23 | 15A | Run-start 6, Blind spot information system, Rear view camera, Adaptive cruise control, Heads-up display, Voltage quality module (start/stop), Front split view camera, Front split view camera module |
24 | 10A | Not used (spare) |
25 | 10A | Run/start anti-lock brake system |
26 | 10A | Run/start powertrain control module |
27 | - | Not used |
28 | 10A | Rear washer pump |
29 | - | Not used |
30 | - | Not used |
31 | - | Not used |
32 | - | Electronic fan 1 relay |
33 | - | A/C clutch relay |
34 | 15A | Glove box release |
35 | - | Not used |
36 | - | Not used |
37 | 10A | Power transfer unit fan |
38 | - | Electronic fan 2 relay |
39 | - | Electric fan 3 relay |
40 | - | Horn relay |
41 | - | Not used |
42 | - | Fuel pump relay |
43 | 10A | 2nd row easy fold seat release |
44 | 20A | LH HID headlamp |
45 | - | Not used |
46 | - | Not used |
47 | - | Not used |
48 | - | Not used |
49 | - | Not used |
50 | 20A | Horn |
51 | - | Not used |
52 | - | Not used |
53 | - | Not used |
54 | 10A | Brake on-off switch |
55 | 10A | ALT sensor |
Engine compartment fuse box - bottom:
Fuse/Relay N° | Rating | Functions |
56 | - | Not used |
57 | - | Not used |
58 | 30A | Fuel pump feed |
59 | 30A | Electronic fan 3 |
60 | 30A | Electronic fan 1 |
61 | - | Not used |
62 | 50A | Body control module 1 |
63 | 25A | Electronic fan 2 |
64 | - | Not used |
65 | 20A | Front heated seat |
66 | - | Not used |
67 | 50A | Body control module 2 |
68 | 40A | Heated rear window |
69 | 30A | Anti-lock brake system valves |
70 | 30A | Passenger seat |
71 | 50A | Active front steering |
72 | 20A | Transmission oil pump (start/stop) |
73 | 20A | Rear heated seats |
74 | 30A | Driver seat module |
75 | 25A | Wiper motor 1 |
76 | 30A | Power liftgate module |
77 | 30A | Climate control seat module |
78 | 40A | Trailer lighting module |
79 | 40A | Blower motor |
80 | 25A | Wiper motor 2 |
81 | 40A | 110 volt inverter |
82 | - | Not used |
83 | 20A | TRCM (iShifter) |
84 | 30A | Starter solenoid |
85 | 30A | Vista roof |
86 | - | Not used |
87 | 60A | Anti-lock brake system pump |
