Kia Sportage 2018 Fuse Box

Kia Sportage 2018 Fuse Box Info



Fuse box location:

The fuse box is located at the left side of the steering column at the bottom of the instrument panel.



Engine compartment fuse box:



Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay Name Rating Functions
MDPS 7.5A MDPS Unit
MODULE 2 10A Headlamp LH/RH
SMART KEY 1 10A Smart Key Control Module/Immobilizer Module
A/BAG IND 7.5A

Instrument Cluster

[Audio & Manual A/C] Hazard Switch [Audio & Auto A/C] A/C Control Module [Navigation] Center Facia Lamp
MODULE 4 10A Console Switch, Blind Spot Detection Radar LH/RH, AWD ECM, Crash Pad Switch, BCM, Lane Departure Warning Control Module
A/BAG 15A SRS Control Module
START 7.5A [W/O Smart Key & IMMO.] ICM Relay Box (Burglar Alarm Relay), Ignition Switch [With Smart Key / IMMO.] Transaxle Range Switch, ECM, Smart Key Control Module
MODULE 3 10A Front/Rear Seat Warmer Control Module, ATM Shift Lever ILL., Front Air Ventilation Seat Control Module, A/V & Navigation Head Unit, Electro Chromic Mirror, Audio, A/C Control Module, Multipurpose Check Connector, Adaptive Front Lighting Module
CLUSTER 10A Instrument Cluster
MODULE 9 20A PCB Block (Fuse - ABS 3, VACUUM PUMP 2, ECU 6, AEB, TCU 2, MODULE)
HEATED STEERING 15A BCM
MODULE 6 7.5A Front/Rear Seat Warmer Control Module, Front Air Ventilation Seat Control Module
MODULE 5 10A BCM, Smart Key Control Module
A/CON 2 7.5A A/C Control Module
MODULE 1 10A BCM, ATM Shift Lever
P/ WINDOW LH 25A Power Window Main Switch
A/CON 1 7.5A A/C Control Module, Cluster Ionizer, E/R Junction Block (Blower Relay)
WIPER RR 15A Rear Wiper Motor, ICM Relay Box (Rear Wiper Relay)
WASHER 15A Multifunction Switch
SMART KEY 3 10A

[W/O Smart Key] Immobilizer Module

[With Smart Key] Smart Key Control Module, Start/Stop Button Switch
STOP LAMP 7.5A Smart Key Control Module, Stop Lamp Switch
P/ WINDOW RH 25A Power Window Main Switch, Passenger Power Window Switch
MEMORY 10A Wireless Charger, Instrument Cluster, Data Link Connector, BCM, ICM Relay Box (Outside Mirror Folding/Unfolding Relay), Electro Chromic Mirror, A/C Control Module, Console Switch
SUN ROOF 1 20A Panorama Sunroof
TAIL GATE OPEN 10A Tail Gate Relay
INTERIOR LAMP 10A Ignition Key Ill.& Door Warning Switch, Room Lamp, Overhead Console Lamp, Front Vanity Lamp LH/RH, Rear Personal Lamp LH/RH, Luggage Lamp, Glove Box Lamp
SMART KEY 2 15A Smart Key Control Module
MODULE 8 7.5A Key Solenoid
MULTI MEDIA 15A Audio, A/V & Navigation Head Unit, Rear USB Charger
S/HEATER DRV/PASS 20A Front Seat Warmer Control Module, Front Air Ventilation Seat Control Module
SUN ROOF 2 20A Panorama Sunroof
P/SEAT (PASS) 30A Passenger Seat Manual Switch
POWER OUTLET 20A Front Power Outlet #1 (Front Cigarette Lighter)
S/HEATER REAR 20A Rear Seat Warmer Control Module
DOOR LOCK 20A Door Lock/Unlock Relay
4WD 20A AWD ECM
MODULE 7 10A Hazard Switch, Driver/Passenger Smart Key Outside Handle, AEB Sensor
AMP 25A AMP
SAFETY P/ WINDOW 25A Driver Safety Power Window Module
HEATED MIRROR 10A Driver/Passenger Power Outside Mirror, A/C Control Module
P/SEAT (DRV) 30A Driver Seat Manual Switch
ACC 10A Rear USB Charger, AMP, Power Outside Mirror Switch, PCB Block(Power Outlet Relay), Smart Key Control Module, Audio, A/V & Navigation Head Unit, BCM, Wireless Charger



Engine compartment fuse box:

Fuse/Relay Name Rating Functions
COOLING FAN 2 80A Cooling Fan Motor
MDPS 80A MDPS Unit
B+ 1 60A Smart Junction Block (IPS 2 (5CH), IPS 3 (2CH), IPS 4 (2CH), IPS 5 (2CH), IPS 6 (1CH), Fuse - AMP)
B+ 2 60A Smart Junction Block (IPS 1 (5CH), Fuse - MODULE 7, SMART KEY 2, SMART KET 3, MODULE 8, STOP LAMP)
B+ 3 50A

Smart Junction Block (Fuse - SUNROOF 1, SUNROOF 2, S/HEATER DRV/PASS, S/HEATER REAR, SAFETY P/WINDOW, Power Window Relay)

BLOWER 40A Blower Relay
REAR HEATED 40A Rear Heated Relay
IG1 40A [W/O Smart Key] Ignition Switch, [With Smart Key] PCB Block (PDM (IG1)/PDM (ACC) Relay)
IG2 30A Start Relay, [W/O Smart Key] Ignition Switch, [With Smart Key] PCB Block (PDM (IG2) Relay)
B+ 4 50A

Smart Junction Block (Fuse - AWD, P/SEAT (DRV), P/SEAT (PASS), TAIL GATE OPEN, DOOR LOCK, Leak Current Autocut Device Relay)

COOLING FAN 1 50A Cooling Fan 1 Relay
ABS 1 40A ESC Control Module, Multipurpose Check Connector
POWER TAIL GATE 40A Power Tail Gate Module
ABS 2 40A ESC Module
COOLING FAN 3 40A Cooling Fan 1 Relay
E-CVVT 1 20A PCM
E-CVVT 2 20A PCM
WIPER FRT 1 30A [W/O Smart Key] Ignition Switch, [With Smart Key] PDM (IG2) Relay
TCU 1 15A PCM
WIPER FRT 2 10A BCM, PCM
ECU 3 20A PCM
HORN 15A Horn Relay
BATTERY MANAGEMENT 10A Battery Sensor
SENSOR 2 10A Fuel Pump Relay, Oil Control Valve, Purge Control Solenoid Valve, Variable Intake Solenoid Valve, RCV Control Solenoid Valve
SENSOR 1 15A Oxygen Sensor (Up/Down)
ECU 2 20A Ignition Coil #1/#2/#3/#4
ECU 4 15A PCM
SENSOR 3 10A E/R Junction Block (Cooling Fan 1 Relay), Canister Close Valve
FUEL PUMP 20A Fuel Pump Relay
AEB 10A AEB Sensor
MODULE 7.5A Stop Lamp Switch
B/ALARM HORN 10A E/R Junction Block (B/Alarm Horn Relay)
H/LAMP HI 10A BI-Function H/LP Relay
ABS 3 10A ESC Module
POWER OUTLET 1 20A Front Power Outlet #2
ECU 6 10A PCM
TCU 2 15A Transaxle Range Switch
B/UP LAMP 10A Rear Bumper Lamp LH/RH, Electro Chromic Mirror
POWER OUTLET 2 20A Rear Power Outlet
ECU 1 30A Engine Control Relay
DEICER 15A E/R Junction Block (Deicer Relay)
VACUUM PUMP 1 20A Vacuum Pump
VACUUM PUMP 2 15A Vacuum Pump, Cooling Fan Motor, Vacuum Switch
