Kia Rondo 2014 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay N° and Name | Rating | Functions |
| 1. P/SEAT DRV | 30A |
4WAY : Driver Lumbar Support Switch 6WAY : Driver Seat Manual Switch |
| 2. P/WDW RH | 25A | Power Window Relay RH, Driver/Passenger Safety Power Window Module, Rear Safety Power Window Module RH |
| 3. P/WDW LH | 25A | Power Window Relay LH, Driver/Passenger Safety Power Window Module, Rear Safety Power Window Module LH |
| 4. DR LOCK | 20A | Door Lock/Unlock Relay, Two Turn Unlock Relay |
| 5. SPARE 1 | 15A | - |
| 6. POWER OUTLET 1 | 20A | Cigarette Lighter, Rear Power Outlet |
| 7. SPARE 2 | 30A | - |
| 8. MODULE 3 | 7.5A | Frt Seat Warmer Sw, Hlld Sw, Navigation, Amp, Rear Seat Warmer Ecu, Auto Hlld Ecu, Heater Control Unit |
| 9. S/HEATER FRT SEAT VENT | 20A | Driver/Passenger Seat Warmer Module |
| 10. MODULE 6 | 10A | A/V & Navigation Head Unit (W/O ISG), Audio (W/O ISG), DC-DC Converter (With ISG), Digital Clock, Smart Key Control Module, BCM, Outside Mirror Switch, Outside Mirror |
| 11. A/CON1 | 7.5A | Cluster Ionizer, A/C Control Module, Blower Relay, PTC Relay |
| 12. MODULE 5 | 7.5A | Head Lamp Washer Relay, Portable Lamp, Passenger Seat Warmer Module, Rear Seat Warmer Module, Driver Seat Warmer Module |
| 13. HTD MIRR | 10A | Driver/Passenger Outside Mirror, ECU, A/C Control Module |
| 14. INTERIOR LAMP | 10A | Glove Box Lamp, Luggage Lamp, Vanity Lamp LH/RH, Room Lamp, Overhead Console Lamp, Door Warning Sw, Foot Lamp LH/RH, Portable Lamp, Door Warning Sw, Puddle Lamp LH/RH, Personal Lamp LH/RH |
| 15. SMART KEY 2 | 10A | Immobilizer Module, Start Stop Button Switch |
| 16. SUNROOF | 20A | Panorama Sunroof |
| 17. MODULE 1 | 7.5A | Electric Parking Brake Module, Rear Parking Assist Sensor, Smart Parking Assist Control Module, Crash Pad Lower Switch, Rear Parking Assist Sensor Buzzer, Tire Pressure Monitoring System |
| 18. HTD STRG | 15A | Steering Wheel Heater |
| 19. ECU | 10A | Immobilizer Module, Smart Key Control Module, ECU, Speed Sensor |
| 20. WIPER | 15A | Front Washer Motor, Rear Wiper Motor, Rear Wiper Relay |
| 21. MEMORY 2 | 7.5A | Rf Receiver |
| 22. MEMORY 1 | 10A | Instrument Cluster, Tire Pressure Monitoring Module, BCM, A/C Control Module, Digital Clock, Data Link Connector, Buzzer |
| 23. CLUSTER | 7.5A | Instrument Cluster, DC-DC Converter (With ISG) |
| 24. MDPS | 7.5A | MDPS Unit |
| 25. SPARE 3 | 20A | - |
| 26. START | 7.5A | Start Relay, ECU, Ignition Lock Switch, Transaxle Range Switch, TCU, Smart Key Control Module |
| 27. MULTI MEDIA | 15A | A/V & Navigation Head Unit (W/O ISG), Audio (W/O ISG), DC-DC Converter (With ISG) |
| 28. SMART KEY 1 | 20A | Smart Key Control Module |
| 29. A/BAG | 15A | SRS Control Module |
| 30. MODULE 2 | 7.5A | Rear Seat Warmer Sw, ICM BOX (Fold’g Rly), AT LEVER Key Sol, ICM BOX (Turn Signal Sound) |
| 31. MODULE 4 | 7.5A | Body Control Module |
| 32. MODULE 7 | 7.5A | Body Control Module, Smart Key Control Module |
| 33. TCU | 15A | M/T : F35 (B/UP LAMP), A/T : Transaxle Range Switch, TCM (D4HB) |
| 34. ABS | 10A | ESC Control Module, ABS Control Module |
| 35. A/CON 2 | 7.5A | A/C Control Module |
| 36. S/HEATER RR | 15A | Rear Seat Warmer LH/RH |
| 37. AMP | 25A | AMP, DC-DC Converter (With ISG) |
| 38. FOG LAMP RR | 10A | ICM Relay Box (Rear Fog Lamp Relay) |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| MDPS | 80A | MDPS Unit |
| IP_B+1 | 60A | Inner Fuse Panel, S/Heater RR, Smart Key 1, 2, P/WDW LH/RH, IPS-1/Arisu-1 (H/Lamp Low RH, H/Lamp Hi RH, Turn FR/RR), IPS-2 (Int Tail Lamp), IPS-4 (Drl Lamp LH/RH), IPS-3 (Frt Fog Lamp LH/RH) |
| ABS_1 | 40A | ESC Control Module, ABS Control Module |
| ABS_2 | 40A | ESC Control Module, ABS Control Module, Multipurpose Check Connector |
| IGN_2 | 40A | W/O Smart Key : Ignition Switch, START RELAY, Starter Fuse No: 26 With Smart Key : IG2 RELAY, START RELAY, IG2 Fuse No: 11, 12, 18, 20, 33 |
| IP_B+2 | 60A | Inner Fuse Panel, P/seat DRV, Spare3, Fog Lamp RR, IPS-5/Arisu-2 (H/Lamp Low LH, H/Lamp Hi LH, Turn FL/RL), IPS-6 (EXT Tail Lamp LH/RH) |
| RR HTD | 40A | RR HTD RELAY RR HTD, MIRR HTD |
| BLOWER | 40A | BLOWER RLY, BLOWER MOTOR |
| IG1 | 40A |
W/O Smart Key : Ignition Switch With Smart Key : IG1 RELAY, ACC RELAY, INNER FUSE PANEL (ACC Fuse No: 5, 6,10 IG1 Fuse No: 8,17,19, 23, 24, 30, 32, 34, 35) |
| EPB_1 | 30A | Electric Parking Brake Module |
| EPB_2 | 30A | Electric Parking Brake Module |
| C/FAN | 50A | C/FAN LO RELAY, C/FAN HI RELAY, C/FAN MOTOR |
| DEICER | 15A | DEICER RELAY |
| STOP LAMP | 15A | SSEM,STOP LAMP |
| EMS | 40A | EMS Box (FUSE No. - 1/2/3/4/5/6/7/8/9) |
| B+3 | 50A | Inner Fuse Panel (Leak Current Autocut Device, Fuse No. - 4/9/14/16/21/22/25/27/31/38) |
| FRT_WIPER_LH | 25A | FRT WIPER LH |
| FRT_WIPER_RH | 25A | FRT WIPER RH |
| B/UP LP | 10A | M/T : Back-up Lamp Switch, A/T : Transaxle Range Switch, TCU |
| ECU4 | 15A | ECU |
| B+4 | 50A | FRT WIPER LH/RH , ECU4 |
| BRAKE_SWITCH | 10A | STOP SIGNAL |
| H/LP_WASHER | 20A | Head Lamp Washer Relay, Head Lamp Washer |
| P/OUTLET 2 | 30A | P/OUTLET RELAY 2 |
| SPARE | 7.5A | SPARE |
