Kia Forte 2015 Fuse Box Info
Passenger fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| P/SEAT DRV | 30A | Driver IMS Module, Driver Seat Manual Switch |
| SPARE 4 | 25A | - |
| P/WDW RH | 25A | Smart Junction Box (Power Window RH Relay), Passenger Safety Power Window Module |
| TRUNK | 10A | Smart Junction Box (Trunk Relay) |
| P/WDW LH | 25A | Smart Junction Box (Power Window LH Relay), Driver Safety Power Window Module |
| DR LOCK | 20A | Smart Junction Box (Door Lock Relay, Door Unlock Relay), ICM Relay Box (Two Turn Unlock Relay) |
| SPARE 3 | 20A | - |
| POWER OUTLET 1 | 20A | Power Outlet |
| S/HEATER RR | 20A | Rear Seat Warmer LH/RH |
| MODULE 8 | 10A | BCM, Smart Key Control Module |
| SPARE 2 | 7.5A | - |
| SPARE 1 | 15A | - |
| MODULE 1 | 10A | Smart Key Control Module, BCM, Digital Clock, Audio, A/V & Navigation Head Unit, Power Outside Mirror Switch, DC-DC Converter, MTS Module |
| A/CON | 7.5A | A/C Control Module, Cluster Ionizer, E/R Fuse & Relay Box (Blower Relay, GSL PTC Relay) |
| MODULE 5 | 7.5A | Sunroof, Driver CCS Control Module, Passenger Seat Warmer Module, Rear Seat Warmer LH/RH |
| HTD MIRR | 10A | ECM/PCM, A/C Control Module, Driver/Passenger Power Outside Mirror |
| INTERIOR LAMP | 7.5A | Trunk Room Lamp, Glove Box Lamp, Vanity Lamp LH/RH, Room Lamp, Overhead Console Lamp, Ignition Key ILL. & Door Warning Switch (W/O Smart Key) |
| MODULE 6 | 7.5A | Sport Mode Switch, Key Solenoid |
| PDM 2 | 7.5A | [With Smart Key] Smart Key Control Module [W/O Smart Key] Immobilizer Module |
| SUNROOF | 20A | Sunroof |
| MODULE 2 | 10A | Electro Chromic Mirror, Multipurpose Check Connector, A/C Control Module, Driver CCS Switch, Driver CCS Control Module, Passenger Seat Warmer Module Driver IMS Module, Passenger Seat Warmer Switch, A/V & Navigation Head Unit, DC-DC Converter, MTS Module, ATM Lever Indicator, PAS Off Switch Rear Seat Warmer LH/RH, Rear Power Window Switch LH/RH |
| HTD STRG | 15A | Steering Wheel Heater |
| IG 1 | 20A | W/O Smart Key : E/R Fuse & Relay Box (Fuse - TCU, ECU 3, ABS 3) |
| WIPER FRT | 25A | Wiper Motor, E/R Fuse & Relay Box (Wiper Relay), Multifunction Switch (Wiper) |
| MULTIMEDIA 2 | 7.5A | Telematics Unit |
| MEMORY | 7.5A | Driver IMS Module, Driver Smart Key Outside Handle, Passenger Smart Key Outside Handle, BCM, Tire Pressure Monitoring Module, Auto Light & Photo Sensor Instrument Cluster, Data Link Connector, Multipurpose Check Connector, Digital Clock, A/C Control Module, Electro Chromic Mirror, Driver Power Outside Mirror Passenger Power Outside Mirror |
| MODULE 7 | 10A | ICM Relay Box (Turn Signal Lamp Sound Relay, Folding Relay, Unfolding Relay) |
| PDM 3 | 7.5A | [With Smart Key] Smart Key Control Module [W/O Smart Key] Immobilizer Module |
| MDPS | 7.5A | MDPS Unit |
| MODULE 3 | 7.5A | Instrument Cluster |
| START | 7.5A | [With Burglar Alarm & W/O Smart Key & W/O IMMO.] ICM Relay Box (Burglar Alarm Relay) [W/O Burglar Alarm or With Smart Key or With IMMO.] Transaxle Range Switch (A/T), E/R Fuse & Relay Box (Start 1 Relay), Smart Key Control Module, ECM |
| MULTIMEDIA 1 | 15A | Audio, A/V & Navigation Head Unit, DC-DC Converter |
| BRAKE SWITCH | 10A | Stop Lamp Switch, Smart Key Control Module |
| PDM 1 | 20A | Smart Key Control Module |
| POWER OUTLET 2 | 20A | Power Outlet |
| A/BAG IND | 7.5A | Instrument Cluster (Air Bag IND.) |
| MODULE 4 | 10A | Crash Pad Switch, Tire Pressure Monitoring Module, Stop Lamp Switch, Digital Clock, BCM, ISG Off Switch, Rear Parking Assist Sensor LH (Out/In) Rear Parking Assist Sensor RH (Out/In), Front Parking Assist Sensor LH/RH |
| A/BAG | 15A | SRS Control Module, Passenger Weight Classification Sensor |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| MDPS | 80A | MDPS Unit |
| B+1 | 60A | Smart Junction Box (ARISU-LT IPS 1 (4CH), Fuse - MODULE 6, MODULE 7, P/WDW LH, P/WDW RH, TRUNK) |
| ABS 1 | 40A | ESC Module |
| C/FAN | 40A | C/Fan 1 Relay, C/Fan 2 Relay |
| RR HTD | 40A | RR HTD Relay |
| BLOWER | 40A | Blower Relay |
| GSL PTC | 60A | GSL PTC Relay |
| B+2 | 60A | Smart Junction Box (ARISU-LT IPS 3 (4CH), ARISU-LT IPS 4 (4CH), IPS 5 (2CH), Fuse - PDM 1, P/SEAT DRV BRAKE SWITCH, S/HEATER RR) |
| B/UP LAMP | 10A | A/T : Electro Chromic Mirror, Audio, A/V & Navigation Head Unit, Rear Combination Lamp (In) LH/RH Smart Junction Box (IPS Control Module), M/T : Back-Up Lamp Switch |
| TCU 1 | 15A | Transaxle Range Switch, Vehicle Speed Sensor, Oil Pump Inverter, E/R Fuse & Relay Box (Fuse - B/UP LAMP ) |
| ABS 3 | 10A | ESC Module, Yaw Rate Sensor |
| ECU 3 | 10A | ECM/PCM |
| A/CON SWITCH | 10A | A/C Control Module, Blower Motor, Blower Relay, ECM/PCM, Blower Resistor |
| WIPER | 10A | ECM/PCM, Wiper Motor, E/R Fuse & Relay Box (Wiper Relay) |
| B+3 | 50A | Smart Junction Box (Leak Current Autocut Device, Fuse - PDM 2, DR LOCK, SUNROOF) |
| EMS | 40A | EMS Box (Engine Control Relay, Fuse -ECU 4, A/CON, F/PUMP) |
| ISG INVERTER | 50A | Oil Pump Inverter |
| DEICER | 15A | ICM Relay Box (Front Deicer Relay) |
| F/PUMP | 20A | F/Pump Relay |
| STOP LAMP | 15A | Stop Signal Electronic Module |
| S/HEATER FRT | 20A | Driver CCS Control Module, Passenger Seat Warmer Module |
| HORN | 15A | Horn Relay, ICM Relay Box (Burglar Alarm Horn Relay) |
| ECU 5 | 15A | G4NC : ECM/PCM |
| IG 2 | 40A | W/O Smart Key : Ignition Switch, Start Relay, With Smart Key : PDM 4 (IG2) Relay, Start 1 Relay |
| ABS 2 | 40A | ESC Module |
| IG 1 | 40A | W/O Smart Key : Ignition Switch, With Smart Key : PDM 3 (IG1) Relay, PDM 2 (ACC) Relay |
Engine compartment fuse panel (EMS BOX):
| Fuse/Relay Name | Rating | Functions |
| F/PUMP | 15A | F/Pump Relay |
| ECU 4 | 15A | ECM/PCM |
| A/CON | 10A | A/CON COMP Relay |
| INJECTOR | 10A | Injector #1/#2/#3/#4, F/Pump Relay, A/CON COMP Relay |
| ECU 2 | 10A | ECM/PCM |
| IGN COIL 1 | 20A | Ignition Coil #1/#2/#3/#4, Condenser |
| SPARE | 20A | - |
| SENSOR 2 | 10A | Oxygen Sensor (Up), Oxygen Sensor (Down), Variable Intake Solenoid Valve, Oil Control Valve #1/#2 Purge Control Solenoid Valve, Canister Close Valve, E/R Fuse & Relay Box (C/Fan 1 Relay, C/Fan 2 Relay) |
| SENSOR 1 | 10A | Camshaft Position Sensor #1/#2 |
