Kia Sorento 2009 Fuse Box Info
Passenger fuse box location:
The fuse box is located on the driver’s side of the vehicle under the instrument panel.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
Fuse/Relay Name | Rating | Functions |
W/SHD | 15A | Rear window defroster |
TPMS | 10A | Tire pressure monitoring system |
WIPER(FRT) | 20A | Front wiper |
DRL/OBD-II | 15A | Daytime running light |
HAZARD | 15A | Hazard warning light |
WIPER(RR) | 10A | Rear wiper |
S/ROOF | 20A | Sunroof |
O/S MIRROR | 10A | Outside rearview mirror |
RELAY COIL | 10A | Ignition coil |
START | 10A | Start motor |
S/WARMER | 20A | Seat warmer |
ACC | 15A | Accessory |
STOP LAMP | 20A | Stop light |
TCCS | 20A | TCS, ESC, Immobilizer |
ROOM LAMP | 10A | Room lamp |
CIGAR(FRT) | 15A | Cigar lighter |
O/S MIRROR DEF | 20A | Outside rearview mirror heater |
ENGINE | 10A | Engine control unit |
METER | 10A | Multi-meter |
ABS IG | 10A | ABS |
A/BAG | 10A | Airbag |
TURN LAMP | 10A | Turn signal light |
POWER SEAT | 30A | Power seat |
DOOR LOCK | 20A | Central door lock |
SPARE | 20A | Spare fuse |
Engine compartment fuse box:
Fuse/Relay Name | Rating | Functions |
HORN | 15A | Horn |
AUDIO | 30A | Audio |
MAIN | 140A | Alternator |
ALTERNATOR | 150A | Alternator |
HEAD (HI) | 15A | Headlight (high) |
HEAD (LO) | 15A | Headlight (low) |
DEF | 25A | Rear window defroster |
MEMORY | 10A | Cluster, ETACS, A/C, Clock, Room lamp |
F/FOG | 15A | Front fog light |
IGN 2 | 30A | Ignition |
ABS | 40A | ABS |
F/PUMP | 20A | Fuel pump |
C/FAN | 30A | Radiator fan |
IGN 1 | 40A | Ignition |
EXT AMP | 30A | Amplifier |
ILLUMI | 10A | Instrument panel illumination |
EXT | 15A | Taillight, Turn signal light |
CENTER P/OUTLET | 15A | Power outlet |
BTN 3 | 40A | In panel B+ |
F/BLW | 30A | Blower |
BTN 1 | 40A | In panel B+ |
BTN 2 | 30A | In panel B+ |
P/TRN | 10A | Power train control system sensors,TCU |
P/OUTLET | 30A | Power outlet |
P/W LH | 25A | Power window (left) |
P/W RH | 25A | Power window (right) |
INJECTOR | 15A | Injector |
IG COIL | 10A | Ignition coil |
O2 SNSR | 15A | O2 sensor |
ECU | 15A | Engine control unit |
SPARE | 25A | Spare fuse |
SPARE | 20A | Spare fuse |
SPARE | 15A | Spare fuse |
SPARE | 10A | Spare fuse |
