Jaguar I-Pace 2021 Fuse Box Info
Passenger compartment fuse box location:
Under hood compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 5A | Battery Sounder |
| 2 | - | - |
| 3 | 5A | Immobilizer |
| 4 | 5A | Diagnostic Socket |
| 5 | 5A | RF receiver |
| 6 | 20A | 12v Socket 2nd Row |
| 7 | 20A | 12v Socket Cubby |
| 8 | - | - |
| 9 | - | - |
| 10 | 30A | Left Front Seat Power |
| 11 | 30A | Right Front Seat Power |
| 12 | 5A | Electric mirrors, Blind spot monitor, Camera |
| 13 | 20A | 12v Socket Load Space |
| 14 | 5A | Forward Camera |
| 15 | 10A | Driver Assistance and Collision Avoidance Systems |
| 16 | 10A | Instrument Panel |
| 17 | 20A | Heated Rear Screen |
| 18 | 10A | Driving Aids and Collision Avoidance Systems Controller |
| 19 | 5A | Telematic Control Unit |
| 20 | 20A | Heated seats, Climate seats |
| 21 | 20A | Heated seats, Climate seats |
| 22 | 25A | Front Right Side Door |
| 23 | 25A | Left Rear Side Door |
| 24 | 25A | Right Rear Side Door |
| 25 | 25A | Left Front Side Door |
| 26 | 10A | Head Up Display (HUD) |
| 27 | 5A | Gear Shift |
| 28 | 5A | Radar Sensor - Corner |
| 29 | 5A | Keyless Vehicle Module |
| 30 | - | - |
| 31 | - | - |
| 32 | 5A | Tire Pressure Monitoring System (TPMS) |
| 33 | 5A | Steering Wheel |
| 34 | 10A | USB Sockets |
| 35 | 15A | Electric Seats, Blind Spot Monitor, Rear Exit Detection |
Under hood compartment fuse box A:
| Fuse/Relay N° | Rating | Functions |
| 1 | 5A | Charge port |
| 2 | - | - |
| 3 | 5A | Air Conditioning (A/C) |
| 4 | - | - |
| 5 | 10A | Heated Steering Wheel |
| 6 | 15A | Front luggage compartment controller |
| 7 | 30A | Headlamp washer |
| 8 | - | - |
| 9 | 15A | Horn |
| 10 | 20A | Heated washer jet |
| 11 | 15A | Electric Vehicle (EV) battery cooling |
| 12 | - | - |
| 13 | 5A | Radar Sensor - Center |
| 14 | 15A | Battery cooling |
| 15 | 15A | Climate control |
| 16 | - | - |
| 17 | 5A | Voltage converter |
| 18 | 5A | Electric Vehicle (EV) battery cooling |
| 19 | 10A | On-board charger |
| 38 | - | - |
| 39 | - | - |
Under hood compartment fuse box B:
| Fuse/Relay N° | Rating | Functions |
| 1 | 5A | Cooling system |
| 2 | 5A | Active Vanes |
| 3 | 5A | Electric Vehicle (EV) control module |
| 4 | 5A | Inverter |
| 5 | - | - |
| 6 | 20A | Park lock |
| 8 | 30A | Screen wash |
| 9 | 20A | Right headlight |
| 10 | 20A | Left headlight |
| 11 | 5A | Park lock |
| 12 | 5A | Engine management system |
| 13 | 10A | Engine management system |
| 14 | 5A | Rear inverter |
| 15 | 5A | Traction battery |
| 16 | 5A | Traction battery |
| 17 | 5A | Coolant pump |
| 25 | 5A | Under hood fuse box 2 |
Under hood compartment fuse box C (High voltage fuse box):
| Fuse/Relay N° | Rating | Functions |
| This fuse box is only accessible by authorized retailers/repairers |
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | - |
| 2 | 5A | Rear switch pack console |
| 3 | - | - |
| 4 | - | - |
| 5 | 20A | Cigar lighter power point |
| 6 | 10A | Wireless phone charger |
| 7 | - | - |
| 8 | 10A | Media hub |
| 9 | 10A | Hands free tailgate |
| 10 | 15A | Touchscreen |
| 11 | 15A | Module Infotainment control |
| 12 | 10A | Chassis control module |
| 13 | 10A | Driver assistance and collision avoidance systems |
| 14 | 3A | Electronic toll reader |
| 15 | 5A | Air suspension monitor |
| 16 | 15A | Switch pack A/C |
| 17 | - | - |
| 18 | 5A | Tailgate antenna unit |
| 19 | 15A | Chassis control module |
| 20 | 5A | Rear switch pack |
| 21 | 30A | Upper tailgate module |
| 22 | 20A | Left heated rear seat |
| 23 | 20A | Right heated rear seat |
| 24 | 60A | Air suspension compressor |
| 25 | - | - |
| 26 | - | - |
| 27 | - | - |
