Honda Insight 2012 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is behind the dashboard on the driver’s side.
Engine compartment fuse box location:
The under-hood fuse boxes is on the positive terminal of the battery, and next to the battery.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Back Up |
| 2 | (7.5A) | TPMS* |
| 3 | 20A | Driver's Power Window |
| 4 | - | Not Used |
| 5 | 10A | Back Up Light |
| 6 | 10A | SRS |
| 7 | 10A | Transmission SOL |
| 8 | 7.5A | OPDS |
| 9 | - | Not Used |
| 10 | 7.5A | A/C |
| 11 | 7.5A | ABS/VSA |
| 12 | 10A | IMA |
| 13 | 20A | ACC Socket |
| 14 | 7.5A | Accessory |
| 15 | 7.5A | Daytime Running Light |
| 16 | 10A | Rear Wiper |
| 17 | 20A | Front Passenger's Power Window |
| 18 | 20A | Rear Passenger's Side Power Window |
| 19 | 20A | Rear Driver's Side Power Window |
| 20 | 15A | Fuel Pump |
| 21 | 15A | Washer |
| 22 | 7.5A | Meter |
| 23 | 10A | Hazard |
| 24 | 10A | Stop/Horn |
| 25 | - | Not Used |
| 26 | 10A | LAF |
| 27 | 30A | Door Lock Main |
| 28 | 20A | Headlight Main |
| 29 | 10A | Small Light |
| 30 | 30A | Radiator Fan motor |
| 31 | 7.5A | IGPS |
| 32 | 10A | Right Headlight Low Beam |
| 33 | 20A | IG Coil |
| 34 | 10A | Left Headlight Low Beam |
| 35 | 15A | Door Lock Motor 2 (Lock) |
| 36 | 15A | Door Lock Motor 1 (Lock) |
| 37 | 30A | ABS/VSA FSR |
| 38 | 15A | Selectable Door Lock |
| 39 | 15A | IGP |
| 40 | - | Not Used |
| 41 | - | Not Used |
| 42 | 10A | IMA 1 |
| 43 | 7.5A | MG Clutch |
| 44 | 7.5A | STS |
| 45 | 7.5A | Hatch Lock |
| 46 | - | Not Used |
| 47 | 30A | Condenser Fan Motor |
| 48 | 10A | Left Headlight High Beam |
| 49 | 15A | Door Lock Motor 2 (Unlock) |
| 50 | 15A | Door Lock Motor 1 (Unlock) |
| 51 | 10A | Right Headlight High Beam |
| 52 | 15A | DBW |
| 53 | 10A | IMA 2 |
| 54 | - | Not Used |
| 55 | 10A | Heated Mirror* |
| 56 | 30A | Front Wiper |
| 57 | 30A | Blower Motor |
| 58 | 30A | ABS/VSA Motor |
| 59 |
30A 40A |
Rear Defogger* |
| 60 |
- 50A |
Not Used IG Main |
* If equipped
Engine compartment fuse box (On the battery):
| Fuse/Relay N° | Rating | Functions |
| 1 | 100A | Battery, Main, ACG |
| 2 | 60A | EPS |
| 3 | 20A | Horn, Stop, Hazard |
Engine compartment fuse box (Next to the battery):
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Ignition Coil (EX) |
| 2 | 15A | Ignition Coil (IN) |
