Honda Pilot 2014 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is underneath the dashboard on the driver’s side.
Engine compartment fuse box location:
Luggage compartment fuse box location:
The rear fuse box is located at the left side of cargo area.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay N° | Rating | Functions |
1 | 7.5A | VTM-4 |
2 | 15A | Fuel Pump |
3 | 10A | ACG |
4 | 7.5A | VSA |
5 | - | Not Used |
6 | - | Not Used |
7 | 10A | Auto Light |
8 | 7.5A | Auto Light |
9 | 7.5A | ODS |
10 | 7.5A | Meter |
11 | 10A | SRS |
12 | 10A | Right Daytime Running Light |
13 | 10A | Left Daytime Running Light |
14 | 7.5A | Small Lights (Interior) |
15 | 15A | Small Lights (Exterior) |
16 | 15A | Right Head Light Low |
17 | 15A | Left Head Light Low |
18 | 20A | Daytime Running Light Main |
19 | 15A | Small Lights Main |
20 |
- 7.5A |
Not Used TPMS |
21 | 20A | Head Light Low Main |
22 | 7.5A | VBSOL2 |
23 | 7.5A | STRLD |
24 | - | Not Used |
25 | - | Not Used |
26 | 20A | Driver’s Power Window |
27 | 20A | HAC OP |
28 | 20A | Moonroof |
29 | 20A | Door Lock |
30 | 20A | Front Passenger’s Power Window |
31 | 30A | Audio Amp |
32 | 20A | Passenger’s Side Rear Power Window |
33 | 20A | Driver’s Side Rear Power Window |
34 | - | Not Used |
35 | 10A | ACC |
36 | 10A | HAC |
37 | 7.5A | Day Light |
38 | 30A | Wiper |
Engine compartment fuse box (Primary):
Fuse/Relay N° | Rating | Functions |
1 |
120A - |
Main Fuse Not Used |
2 |
80A 50A |
OP Main IG Main |
3 |
40A 30A |
Blower AC Inverter |
4 |
50A 40A |
Head Light Main Power Window Main |
5 | - | Not Used |
6 | 30A | Condenser Fan |
7 | 30A | Cooling Fan |
8 | 30A | Rear Defogger |
9 | - | Not Used |
10 | 20A | Fog Lights |
11 | 15A | Sub |
12 | 10A | ACM |
13 | 20A | Front Passenger’s Power Seat Reclining |
14 | 20A | Front Passenger’s Power Seat Slide |
15 | 7.5A | Oil Level |
16 | 7.5A | FI ECU |
17 | 20A | Radio |
18 | 15A | IG Coil |
19 | 15A | Main |
20 | 7.5A | MG Clutch |
21 | 15A | DBW |
22 | 10A | Interior Light |
23 | 10A | Back UP |
Engine compartment fuse box (Secondary):
Fuse/Relay N° | Rating | Functions |
1 | 40A | Power Tail Gate Motor |
2 | 20A | VTM-4 |
3 | 30A | Trailer Main |
4 | 40A | VSA FSR |
5 | 30A | Rear Blower |
6 | 30A | VSA Motor |
7 | 15A | Hazard |
8 | 20A | Power TailGate Closer |
9 | 20A | Driver’s Power Seat Reclining |
10 | 20A | Driver’s Power Seat Slide |
11 | 20A | Stop & Horn |
12 | 15A | Rear Console Accessory Socket |
13 | 10A | Rear Wiper |
14 | 20A | Trailer E-Brake |
15 | 20A | Front Heated Seat |
16 | 15A | Center Console Accessory Socket |
17 | 20A | Trailer Charge |
18 | 15A | Front Accessory Socket |
19 | 15A | Rear Accessory Socket |
20 | 20A | Glass Hatch Motor |
21 | 15A | Rear Heated Seat |
22 | 30A | Head Light Washer Motor |
Luggage compartment fuse box:
Fuse/Relay N° | Rating | Functions |
1 | 20A | Small Light |
2 | 7.5A | Stop Lamp |
3 | 7.5A | Back Lamp |
4 | 7.5A | Turn Lamp, Hazard |
