Ford Fiesta 2016 Fuse Box Info
Passenger compartment fuse box location:
The fuse panel is located behind the glove box. Open the glove box, press the sides inward and swing the glove box down.
Engine compartment fuse box location:
The power distribution box is located in the engine compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay N° | Rating | Functions |
Fuses | ||
1 | 15 A | Ignition switch |
2 | 7.5 A | Auto-dimming interior mirror, Autowipers, Heater relay control |
3 | 7.5 A | Instrument cluster |
4 | 7.5 A | Passenger airbag deactivation indicator, passenger sensing system |
5 | 15 A | On-board diagnostics connector |
6 | 10 A | Reversing lamps |
7 | 7.5 A | Instrument panel, information and entertainment display |
8 | 7.5 A | Moonroof |
9 | 20 A | Remote keyless entry, Remote keyless starting |
10 | 15 A | Audio unit, SYNC module |
11 | 20 A | Windshield wipers |
12 | 7.5 A | Climate control |
13 | 15 A | Rear window wiper |
14 | 20 A | Remote keyless entry, Remote keyless starting |
15 | 15 A | Windshield wipers |
16 | 5 A | Exterior mirrors, Power windows |
17 | 15 A | Heated seats |
18 | 10 A | Brake lamp |
19 | 7.5 A | Instrument cluster |
20 | 10 A | Airbags |
21 | 7.5 A | Electronic power assisted steering, Instrument cluster, Ignition, Windshield wipers, Passive anti-theft system |
22 | 7.5 A | Transmission control unit, Powertrain control module, Anti-lock brake system, Stability assist |
23 | 7.5 A | Transmission control unit |
24 | 7.5 A | Audio unit |
25 | 7.5 A | Exterior mirrors |
26 | 7.5 A | Central locking system |
27 | - | Not used |
28 | - | Not used |
29 | - | Not used |
30 | - | Not used |
31 | 30 A | Power windows |
32 | 20 A | Battery back-up sounder |
33 | 20 A | Auxilliary power points |
34 | 30 A | Power windows |
35 | 20 A | Moonroof |
36 | - | Not used |
Relays | ||
R1 | - | Ignition relay |
R2 | - | Not used |
R3 | - | Not used |
R4 | - | Driver heated seat |
R5 | - | Passenger heated seat |
R6 | - | Remote keyless starting |
R7 | - | Remote keyless starting |
R8 | - | Battery back-up sounder |
R9 | - | Accessory delay |
Engine compartment fuse box:
Fuse/Relay N° | Rating | Functions |
Fuses | ||
1 |
40 A 60 A |
Anti-lock brake system module Stability assist, Anti-lock brake system module |
2 |
40 A 60A |
Engine cooling fan relay High speed engine cooling fan relay5 |
3 | 60A | Passenger compartment fuse box |
4 | 20 A | Body control module, Door locks |
5 | - | Not used |
6 | 40 A | Blower motor relay, Blower motor |
7 | - | Not used |
8 | - | Not used |
9 | 7.5 A | Foglamp relay coil, High beam relay coil |
10 | 15 A | Body control module, Right-hand side exterior lighting |
11 | 15 A | Body control module, Left-hand side exterior lighting |
14 | - | Not used |
15 | - | Not used |
16 | - | Not used |
17 | - | Not used |
18 | - | Not used |
19 | 30 A | Fuel injectors |
20 | - | Not used |
21 |
7.5 A 10A |
Mass air flow sensor2 Fuel injector driver |
22 | 15A | Powertrain control module |
23 | 15 A | Camshaft sensor, Heated exhaust gas oxygen sensors |
24 |
15 A 20A |
Ignition coil3 Ignition coil2 |
25 | 10 A | Variable cam timing 1, Variable cam timing 2, Canister purge valve, R5, R6 and R7 relay coil |
26 |
7.5A 15A |
ECSS system4 Active grill shutter, Water pump, Air conditioning1 |
27 | - | Not used |
28 | - | Not used |
29 | - | Not used |
30 | - | Not used |
31 | - | Not used |
32 | 60 A | Passenger compartment fuse box |
33 | 60A | Power windows |
34 |
40 A 60A |
Transmission control module6 High speed engine cooling fan1 |
35 | 40 A | Stability assist/anti-lock brake system valve |
36 | 30 A | Starter inhibit relay, Starter motor solenoid |
37 | 30 A | Heated rear window, Heated mirrors |
38 | 20 A | Body control module, Battery saver |
39 | 15A | Body control module, Direction indicators |
40 | - | Not used |
41 | 10A | Air condition clutch solenoid |
42 | 7.5A | Powertrain control module, Transmission control module, Canister vent valve |
43 | - | Not used |
48 | 10A | Left-hand fog lamp |
49 | 10A | Right-hand fog lamp |
55 | 10A | Left-hand high beam |
56 | 10A | Right-hand high beam |
Relays | ||
R12 | - | Powertrain control module relay |
R13 | - | High beam relay |
R43 | - | Not used |
R44 | - | Foglamp relay |
R45 | - | Air conditioning clutch relay |
R46 | - | Not used |
R47 | - | Fuel pump relay |
R50 | - | High speed cooling fan1 |
R51 | - | Starter inhibit relay |
R52 | - | Blower motor relay |
R53 | - | Not used |
R54 | - | Reversing lamp |
R57 | - | Engine cooling fan relay |
Fuses:
1: 1.0L EcoBoost
2: 1.0L and 1.6L EcoBoost
3: 1.6L Sigma
4: 1.6L Flex-fuel
5: 1.6L Ecoboost
6: 6-Speed PowerShift Transmission
Relays:
1: 1.0L and 1.6L EcoBoost
