Ford Fiesta 2015 Fuse Box

Ford Fiesta 2015 Fuse Box Info



Fuse box location:

The fuse panel is located behind the glove box. Open the glove box, press the sides inward and swing the glove box down.



Engine compartment fuse box:

The power distribution box is located in the engine compartment.



Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
1 15 A Ignition switch
2 7.5 A Auto-dimming interior mirror, Autowipers, Heater relay control
3 7.5 A Instrument cluster
4 7.5 A Passenger airbag deactivation indicator, passenger sensing system
5 15 A On-board diagnostics connector
6 10 A Reversing lamps
7 7.5 A Instrument panel, information and entertainment display
8 7.5 A Moonroof
9 20 A Remote keyless entry, Remote keyless starting
10 15 A Audio unit, SYNC module
11 20 A Windshield wipers
12 7.5 A Climate control
13 15 A Rear window wiper
14 20 A Remote keyless entry, Remote keyless starting
15 15 A Windshield wipers
16 5 A Exterior mirrors, Power windows
17 15 A Heated seats
18 10 A Brake lamp
19 7.5 A Instrument cluster
20 10 A Airbags
21 7.5 A Electronic power assisted steering, Instrument cluster, Ignition, Windshield wipers, Passive anti-theft system
22 7.5 A Transmission control unit, Anti-lock brake system, Stability assist
23 7.5 A Transmission control unit
24 7.5 A Audio unit
25 7.5 A Exterior mirrors
26 7.5 A Central locking system
27 - Not used
28 - Not used
29 - Not used
30 - Not used
31 30 A Power windows
32 20 A Battery back-up sounder
33 20 A Auxilliary power points
34 30 A Power windows
35 20 A Moonroof
36 - Not used
R1 - Ignition relay
R2 - Not used
R3 - Not used
R4 - Driver heated seat
R5 - Passenger heated seat
R6 - Remote keyless starting
R7 - Remote keyless starting
R8 - Battery back-up sounder
R9 - Accessory delay



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
1

60 A

40 A

Stability assist

Anti-lock brake system *

2 40 A Transmission control module
3

40 A

60 A

Cooling fan

Cooling fan module ***

4 40 A Blower motor
5 60 A Passenger compartment fuse box supply
6 30 A Central locking system
7 60 A Ignition switch
8 60 A Powertrain control module
9 40 A Stability assist module
10 30 A Engine start inhibitor
11 30 A Fuel system
12 60 A Power windows
13 60 A High speed cooling fan **
14 - Not used
15 - Not used
16 - Not used
17 20 A High beam
18 15 A Powertrain control module
19 20 A Front fog lamps
20 15 A Emissions system
21 7.5 A High beam
22

15 A

20 A

Ignition coil

Ignition coil ***

23 15 A Right-hand exterior lamps
24 10 A Emissions system
25 15 A Left-hand exterior lamps
26 20 A Horn, battery back-up sounder, interior lamps
27

7.5 A

15 A

Engine cold start system module ****

Water pump **, active grill shutter **

28 15 A Direction indicators
29 20 A Compressed natural gas, fuel control module *
30 10 A Air conditioning clutch
31 - Not used
32 7.5 A Powertrain control module, transmission control unit
33

10 A

7.5 A

Fuel injectors

Mass air flow sensor ***

34 30 A Heated exterior mirrors
35 10 A Left-hand fog lamp
36 10 A Right-hand fog lamp
37 10 A Left-hand high beam
38 10 A Right-hand high beam
39 - Not used
40 - Not used
41 - Not used
42 - Not used
43 - Not used
44 - Not used
45 - Not used
46 - Not used
R1 - Compressed natural gas fuel system *
R2 - Not used
R3 - Powertrain control module
R4 - Blower motor
R5 - Cooling fan *
R6 - Air condition clutch
R7 - High speed cooling fan **
R8 - Not used
R9 - Engine start inhibitor
R10 - High beam
R11 - Front fog lamps
R12 - Reversing lamp ***
R13 - Fuel pump



Fuses:

* If equipped

** 1.0L EcoBoost

*** 1.0L and 1.6L EcoBoost

**** 1.6L Flex-fuel



Relays:

* If equipped

** 2 1.0L and 1.6L EcoBoost

*** 6-Speed PowerShift Transmission.
