Ford Ka 2008 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is under the dashboard on the driver’s side (LHT).
The interior fuse box is behind the glove box on the passinger’s side (RHT).
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 12 | 7.5A | Right dipped beam power supply |
| 13 | 7.5A | Left dipped headlight and headlight alignment control unit power supply |
| 31 | 5A | Engine compartment junction unit switch |
| 32 | 7.5A | Front and rear courtesy lights, boot and puddle lights |
| 36 | 10A | Diagnostic socket, radio, climate control, EOBD |
| 37 | 5A | Brake light switch, instrument panel node |
| 38 | 20A | Door central locking |
| 43 | 15A | Windscreen/ rear window washer pump |
| 47 | 20A | Driver side power windows |
| 48 | 20A | Passenger side power windows |
| 49 | 5A | Parking sensor, backlighting switches, electric mirrors |
| 50 | 7.5A | Airbag node |
| 51 | 7.5A | Radio switch, convergence, climate control, brake lights, clutch |
| 53 | 5A | Instrument panel node |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 01 | 60A | Body computer control unit |
| 02 | 20A | Subwoofer, hi-fi audio amplifier |
| 03 | 20A | Ignition switch |
| 04 | 40A | ABS control unit (pump power supply) |
| 05 | 70A | EPS |
| 06 | 20A | Single-speed engine cooling fan |
| 06 | 30A | Single-speed engine cooling fan, low speed engine cooling fan |
| 07 | 40A | High-speed engine cooling fan |
| 08 | 30A | Climate control system fan |
| 09 | - | Spare |
| 10 | 15A | Horns |
| 11 | 10A | Engine control system (secondary loads) |
| 14 | 15A | Main headlights |
| 15 | 15A | Heated seats |
| 16 | 7.5A | +15 Engine control unit |
| 17 | 10A | Engine control unit |
| 18 | 7.5A | Engine control unit (1.2L Duratec) |
| 18 | 7.5A | Engine control unit, relay coil (1.3L Duratorq) |
| 19 | 7.5A | Conditioner compressor |
| 20 | 30A | Heated rear window, mirror demisters |
| 21 | 15A | Fuel pump |
| 22 | 15A | Ignition coil, injectors (1.2L Duratec) |
| 22 | 20A | Engine control unit (1.3L Duratorq) |
| 23 | 20A | ABS control unit (Control unit power supply + Solenoids) |
| 24 | 7.5A | +15 ABS control unit (pump power supply), EPS, yaw sensor |
| 30 | 15A | Fog headlights |
| 81 | 50A | Glow plug control unit (1.3L Duratorq) |
| 82 | - | Spare |
| 83 | 50A | Heated windscreen |
| 84 | - | Spare |
| 85 | 15A | Front socket (with or without cigar lighter plug) |
| 87 | 7.5A | +15 for reversing lights, debimeter, presence of water in diesel sensor, relay coils T02, T05, T14 and T19 |
| Relays | ||
| 02 | 20A | Main headlights |
| 03 | 20A | Buzzers |
| 05 | 20A | Conditioner compressor |
| 06 | 30A | Single-speed engine cooling fan, Low speed engine cooling fan |
| 07 | 50A | High-speed engine cooling fan |
| 08 | 30A | Climate control system fan |
| 09 | 30A | Engine control system (main relay) |
| 10 | 20A | Heated seats |
| 14 | 20A | Fog headlights |
| 17 | 30A | Fuel pump |
| 19 | 30A | Demisting |
| 20 | - | Spare |
| 30 | 50A | Heated windscreen |
| 31 | 30A | Front socket (with or without cigar lighter plug) |
