Fiat Qubo 2022 Fuse Box

Fiat Qubo 2022 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located on the driver's side under the instrument panel.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
12* 7.5A Dipped headlight (passenger side)
13 7.5/5*A Dipped headlight (driver side)/Headlight adj.
31 5A INT/A SCM relay coils
32* 7.5A Timed interior lighting
36 10A Radio node/Bluetooth® system control unit /EOBD system control unit/Volumetric alarm control unit/Alarm siren control unit
37 5A Instrument panel node/Stop light control (NO)
38 20A Door/boot lock actuators*
43 15A Windshield washer/rear window washer bidirectional pump
47 20A Front electric window (driver side)*
48 20A Front electric window (passenger side)*
49 5A Controls lighting/Parking sensors control unit/Electric wing
mirrors control/Volumetric alarm control unit
51 7.5A INT Radio node/Bluetooth® system control unit /Electric
mirror movement/Clutch switch/Brake lights (NC)
53 5A Instrument panel node
41 7.5A Door mirror defrosters
45 - Spare
46 - Spare
90 - Spare
91 - Spare
92 - Spare
93 - Spare
94 15A Cigar lighter/Passenger compartment power socket
95 - Spare
96 15A Cigar lighter/Passenger compartment power socket
97 10A Front seat heater (driver side)
98 10A Front seat heater (passenger side)

* Some versions only



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
09 15A Spare (trailer kit)
10 10A Horns
14 15A Main beam headlights
15 15A Rear power socket
19 7.5A Climate control compressor
20 30A Heated rear window, mirror defrosters
21 15A Fuel pump
08 15A Fog lights
85 30A Cigar lighter/Passenger compartment socket/Heated seats/USB APO
87 7.5A IBS battery charge sensor for Start&Stop system (1.3 Multijet Euro 6 with Start&Stop)
