Fiat Qubo 2019 Fuse Box

Fiat Qubo 2019 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located on the driver's side under the instrument panel.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
12* 7.5A Dipped headlight (passenger side)
13 7.5/5*A Dipped headlight (driver side)/Headlight alignment corrector
31 5A INT/A SCM relay coils
32* 7.5A Timed interior lighting
36 10A Radio node/Bluetooth® system control unit/Blue&Me™ mode/EOBD system control unit/Volumetric alarm control unit/Alarm siren control unit
37 5A Instrument panel node/Stop light control (NO)
38 20A Door/boot lock actuators*
43 15A Windshield washer/rear window washer bidirectional pump
47 20A Front electric window (driver side)*
48 20A Front electric window (passenger side)*
49 5A Controls lighting/Parking sensors control unit/Electric wing mirrors control/Volumetric alarm control unit
51 7.5A INT Radio node/Bluetooth® system control unit/Blue&Me™ node/Electric mirror movement/Clutch switch/Brake lights (NC)
53 5A Instrument panel node
41 7.5A Door mirror defrosters
45 - Spare
46 - Spare
90 - Spare
91 - Spare
92 - Spare
93 - Spare
94 15A Cigar lighter/Passenger compartment power socket
95 - Spare
96 15A Cigar lighter/Passenger compartment power socket
97 10A Front seat heater (driver side)
98 10A Front seat heater (passenger side)

* Some versions only



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
09 15A Spare (trailer kit)
09 10A Methane system solenoid valves (CNG)
10 10A Horns
14 15A Main beam headlights
15 15A Rear power socket
16 7.5A Dualogic™ transmission control unit and gear selector lever (+ ignition power supply)
19 7.5A Air conditioner compressor
20 30A Heated rear window, mirror defrosters
21 15A Fuel pump
08 15A Fog lights
82 30A Dualogic™ pump power supply (+ battery)
84 15A Dualogic™ transmission control unit (+ battery power supply)
85 30A Cigar lighter/Passenger compartment socket/Heated seats/USB APO
87 7.5A IBS battery charge sensor for Start&Stop system (1.3 Multijet Euro 6 with Start&Stop)
