Fiat Qubo 2021 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located on the driver's side under the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay N° | Rating | Functions |
12* | 7.5A | Dipped headlight (passenger side) |
13 | 7.5/5*A | Dipped headlight (driver side)/Headlight alignment corrector |
31 | 5A | INT/A SCM relay coils |
32* | 7.5A | Timed interior lighting |
36 | 10A | Radio node/Bluetooth® system control unit /EOBD system control unit/Volumetric alarm control unit/Alarm siren control unit |
37 | 5A | Instrument panel node/Stop light control (NO) |
38 | 20A | Door/boot lock actuators* |
43 | 15A | Windshield washer/rear window washer bidirectional pump |
47 | 20A | Front electric window (driver side)* |
48 | 20A | Front electric window (passenger side)* |
49 | 5A | Controls lighting/Parking sensors control unit/Electric wing mirrors control/Volumetric alarm control unit |
51 | 7.5A | INT Radio node/Bluetooth® system control unit /Electric mirror movement/Clutch switch/Brake lights (NC) |
53 | 5A | Instrument panel node |
41 | 7.5A | Door mirror defrosters |
45 | - | Spare |
46 | - | Spare |
90 | - | Spare |
91 | - | Spare |
92 | - | Spare |
93 | - | Spare |
94 | 15A | Cigar lighter/Passenger compartment power socket |
95 | - | Spare |
96 | 15A | Cigar lighter/Passenger compartment power socket |
97 | 10A | Front seat heater (driver side) |
98 | 10A | Front seat heater (passenger side) |
* Some versions only
Engine compartment fuse box:
Fuse/Relay N° | Rating | Functions |
09 | 15A | Spare (trailer kit) |
10 | 10A | Horns |
14 | 15A | Main beam headlights |
15 | 15A | Rear power socket |
19 | 7.5A | Climate control compressor |
20 | 30A | Heated rear window, mirror defrosters |
21 | 15A | Fuel pump |
08 | 15A | Fog lights |
85 | 30A | Cigar lighter/Passenger compartment socket/Heated seats/USB APO |
87 | 7.5A | IBS battery charge sensor for Start&Stop system (1.3 Multijet Euro 6 with Start&Stop) |
