Fiat 124 Spider 2017 Fuse Box Info
Passenger fuse box location:
The fuse box is located on the vehicle's left side.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N°and Name | Rating | Functions |
| 01 RHT R | 30A | - |
| 02 RHT L | 30A | - |
| 03 | - | - |
| 04 | - | - |
| 05 F.OUTLET | 15A | Accessory Sockets |
| 06 | - | - |
| 07 AT IND | 7.5A | AT Shift Indicator — If Equipped |
| 08 MIRROR | 7.5A | Power Control Mirror |
| 09 R_DECK R | 30A | - |
| 10 R_DECK L | 30A | - |
| 11 F.WASHER | 15A | Windshield Washer |
| 12 P.WINDOW | 30A | Power Windows |
| 13 | - | - |
| 14 SRS2/ESCL | 15A | - |
| 15 | - | - |
| 16 | - | - |
Engine compartment fuse box:
| Fuse/Relay N° and Name | Rating | Functions |
| 01 ENG IG3 | 5A | Engine Control Systems |
| 02 ENG IG2 | 5A | Engine Control Systems |
| 03 HORN2 | 7.5A | Horn |
| 04 C/U IG1 | 15A | For Protection Of Various Circuits |
| 05 ENG IG1 | 7.5A | Engine Control System |
| 06 | - | - |
| 07 INTERIOR | 15A | Overhead Light |
| 08 | - | - |
| 09 AUDIO2 | 15A | Audio System |
| 10 METER1 | 10A | Instrument Cluster |
| 11 SRS1 | 7.5A | Air Bag |
| 12 | - | - |
| 13 RADIO | 7.5A | Audio System |
| 14 ENGINE3 | 20A | Engine Control System |
| 15 ENGINE1 | 10A | Engine Control System |
| 16 ENGINE2 | 15A | Engine Control System |
| 17 AUDIO1 | 25A | Audio System |
| 18 A/C MAG | 7.5A | Air Conditioner |
| 19 AT PUMP H/L HI | 20A | Transmission Control System (If Equipped) |
| 20 AT | 15A | Transmission Control System (If Equipped) |
| 21 D LOCK | 25A | Power Door Locks |
| 22 H/L RH | 20A | Headlight (RH) |
| 23 ENG + B2 | 7.5A | Engine Control System |
| 24 TAIL | 20A | Taillights/Number Plate Lights/Position Lights |
| 25 | - | - |
| 26 ROOM | 25A | Overhead Light |
| 27 FOG | 15A | Fog Lights |
| 28 H/CLEAN | 20A | Headlight Washer (If Equipped) |
| 29 STOP | 10A | Stop Lights/Rear Fog Light (If Equipped) |
| 30 HORN | 15A | Horn |
| 31 H/L LH | 20A | Headlight (LH) |
| 32 ABS/DSC S | 30A | ABS/DSC System |
| 33 HAZARD | 15A | Hazard Warning Flashers/Direction Indicators Lights |
| 34 FUEL PUMP | 15A | Fuel System |
| 35 ENG + B3 | 5A | Engine Control System |
| 36 WIPER | 20A | Windshield Wipers |
| 37 CABIN + B | 50A | For Protection Of Various Circuits |
| 38 | - | - |
| 39 | - | - |
| 40 ABS/DSC M | 50A | ABS/DSC System |
| 41 EVVT A/R PUMP | 20A | Engine Control System |
| 42 | - | - |
| 43 | - | - |
| 44 FAN2 | 40A | Cooling Fan |
| 45 ENG.MAIN | 40A | Engine Control System |
| 46 EPS | 60A | Power Steering System |
| 47 DEFOG | 30A | Rear Window Defogger |
| 48 IG2 | 30A | For Protection Of Various Circuits |
| 49 | - | - |
| 50 HEATER | 40A | Air Conditioner |
| 51 | - | - |
| 52 | - | - |
