Dodge Grand Caravan 2011 Fuse Box Info
Fuse box location:
Fuse Box Diagram | Layout
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| J1 | 40A | Power Folding Seat |
| J2 | 30A | Power Liftgate Module |
| J3 | 30A | Rear Door Module (RR Door Node) |
| J4 | 25A | Driver Door Node |
| J5 | 25A | Passenger Door Node |
| J6 | 40A | Antilock Brakes Pump/Stability Control System |
| J7 | 30A | Antilock Brakes Pump/Stability Control System |
| J8 | 40A | Power Memory Seat (If Equipped) |
| J9 | 40A | Partial Zero Emissions Vehicle Motor/ Flex Fuel |
| J10 | 30A | Headlamp Wash Relay/Manifold Tuning Valve |
| J11 | 30A | Power Sliding Door Module/Anti–Theft Module Relay Lock Feed |
| J13 | 60A | Ignition Off Draw (IOD) — Main |
| J14 | 40A | Rear Window Defogger |
| J15 | 30A | Front Blower |
| J17 | 40A | Starter Solenoid |
| J18 | 20A | Powertrain Control Module Trans Range |
| J19 | 60A | Radiator Fan |
| J20 | 30A | Front Wiper LO/HI |
| J21 | 20A | Front/Rear Washer |
| J22 | 25A | Sunroof Module |
| M1 | 15A | Rear Center Brake Lamp/Brake Switch |
| M2 | - | - |
| M3 | 20A | Spare Fuse |
| M4 | 10A | Trailer Tow |
| M5 | 25A | Inverter |
| M6 | 20A | Power Outlet #1 (ACC), Rain Sensor |
| M7 | 20A | Power Outlet #2 (BATT/ACC SELECT) |
| M8 | 20A | Front Heated Seat (If Equipped) |
| M9 | 20A | Rear Heated Seat (If Equipped) |
| M10 | 15A | Ignition Off Draw — Video System, Satellite Radio, DVD, Hands-Free Module, Universal Garage Door Opener, Vanity Lamp, Streaming Video Module |
| M11 | 10A | Ignition Off Draw – Climate Control System |
| M12 | 30A | Amplifier (AMP)/ Radio |
| M13 | 20A | Ignition Off Draw— Instrument Cluster, SIREN, Clock Module, Multi-Function Control Switch/ITM |
| M14 | 20A | Spare Fuse |
| M15 | 20A | Rear View Mirror, Instrument Cluster, Multi-Function Control Switch, Tire Pressure Monitor, Glow Plug Module – Export Diesel Only, Assy-Shifter (Hall Effect), Acoustic Noise Cancellation |
| M16 | 10A | Airbag Module/ Occupant Classification Modul |
| M17 | 15A | Left Tail/License/ Park Lamp, Running Lamps |
| M18 | 15A | Right Tail/Park/Run Lamp |
| M19 | 25A | Automatic Shutdown #1 and |
| M20 | 15A | Instrument Cluster Interior Light, Switch Bank, Steering Column Module, Switch Steering Wheel |
| M21 | 20A | Automatic Shutdown #3 |
| M22 | 10A | Right Horn (HI/ LOW) |
| M23 | 10A | Left Horn (HI/ LOW) |
| M24 | 25A | Rear Wiper |
| M25 | 20A | Fuel Pump, Diesel Lift Pump – Export Only |
| M26 | 10A | Power Mirror Switch, Driver Window Switch |
| M27 | 10A | Ignition Switch, Wireless Control Module, Keyless Entry Module, Steering Column Lock |
| M28 | 10A | Powertrain Control Module, Transmission Feed, Transmission Control Mod |
| M29 | 10A | Occupant Classification Module |
| M30 | 15A | Rear Wiper Module, Power Folding Mirror, J1962 Diagnostic Feed |
| M31 | 20A | Back-Up Lamps |
| M32 | 10A | Airbag Module, TT EUROPE |
| M33 | 10A | Powertrain Control Module, Transmission Control Module |
| M34 | 10A | Park Assist, Heater Climate Control System Module, Headlamp Wash, Compass, IR Sensor, Rear Camera, Lamp Door FT Drv/Pass, Lamp Flashlight, AHLM, Relay Diesel Cabin Heater, Rad Fan Diesel |
| M35 | 10A | Heated Mirrors |
| M36 | 20A | Power Outlet #3 |
| M37 | 10A | Antilock Brakes, Stability Control System, Stop Lamp Switch, Fuel Pump Rly Hi Control |
| M38 | 25A | Door Lock/Unlock Motors, Liftgate Lock/Unlock Motors |
