Dodge Grand Caravan 2009 Fuse Box Info
Fuse box location:
Fuse Box Diagram | Layout
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| J1 | 40A | Power Folding Seat |
| J2 | 30A | Power Liftgate Module |
| J3 | 30A | Rear Door Module (RR DOOR NODE) |
| J4 | 25A | Driver Door Node |
| J5 | 25A | Passenger Door Node |
| J6 | 40A | Anti-Lock Brake System (ABS) Pump/ESP |
| J7 | 30A | Anti-Lock Brake System (ABS) Valve/ESP |
| J8 | 40A | Power Memory Seat (If Equipped) |
| J9 | 40A | PZEV Motor/Flex Fuel |
| J10 | 30A | Headlamp Wash Relay/Manifold Tuning Valve |
| J11 | 30A | Power Sliding Door Module/Thatchum Relay Lock Feed |
| J13 | 60A | Ignition Off Draw (IOD) — Main |
| J14 | 40A | Rear Window Defogger |
| J15 | 30A | Rear Blower |
| J17 | 40A | Starter Solenoid |
| J18 | 20A | Powertrain Control Module (PCM) Trans Range |
| J19 | 60A | Radiator Fan |
| J20 | 30A | Front Wiper LO/HI |
| J21 | 20A | Front/Rear Washer |
| J22 | 25A | Sunroof Module |
| M1 | 15A | Center High Mounted Stop Light (CHMSL)/ Brake Switch |
| M2 | - | - |
| M3 | 20A | Spare Fuse |
| M4 | 10A | Trailer Tow |
| M5 | 25A | Inverter |
| M6 | 20A | Power Outlet #1 (ACC), Rain Sensor |
| M7 | 20A | Power Outlet #2 (BATT/ACC SELECT) |
| M8 | 20A | Front Heated Seat (If Equipped) |
| M9 | 20A | Rear Heated Seat (If Equipped) |
| M10 | 15A | Ignition Off Draw — Vehicle Entertainment System (IOD-VES), Satellite Digital Audio Receiver (SDARS), DVD, Hands-Free Module (HFM), Universal Garage Door Opener (UGDO), Vanity Lamp (VANITY LP), Streaming Video Module |
| M11 | 10A | (Ignition Off Draw) IOD-HVAC/ATC |
| M12 | 30A | Amplifier (AMP)/ Radio |
| M13 | 20A | Ignition Off Draw— Cabin Compartment Node (IOD-CCN), SIREN, Clock Module (CLK MOD), MultiFunction Control Switch (MULTIFCTN SW)/ITM |
| M14 | 20A | Spare Fuse |
| M15 | 20A | Rear View Mirror (RR VW MIR), Cabin Compartment Node (CCN), MultiFunction Control Switch (MULTIFTCN SW), Tire Pressure Monitor (TPM), Glow Plug Module (GLW PLG MOD) — Export Diesel Only, AssyShifter (Hall Effect), Acoustic Noise Cancellation (ANC) |
| M16 | 10A | Occupant Restraint Controller/Occupant Classification Module (ORC/OCM) |
| M17 | 15A | Left Tail/License/ Park Lamp (LT-TAIL/ LIC/PRK LMP), Running Lamps |
| M18 | 15A | Right Tail/Park/Run Lamp (RT-TAIL/ PRK/RUN LMP) |
| M19 | 25A | Auto Shut Down (ASD #1 and #2) |
| M20 | 15A | Cabin Compartment Node Interior Light (CCN INT LIGHT), Switch Bank (SW BANK), Steering Control Module (SCM), Switch Steering Wheel |
| M21 | 20A | Auto Shut Down (ASD #3) |
| M22 | 10A | Right Horn (RT HORN (HI/LOW) |
| M23 | 10A | Left Horn (LT HORN (HI/LOW) |
| M24 | 25A | Rear Wiper (REAR WIPER) |
| M25 | 20A | Fuel Pump (FUEL PUMP), Diesel Lift Pump (DSL LIFT PUMP) — Export Only |
| M26 | 10A | Power Mirror Switch (PWR MIRR SW), Driver Window Switch (DRVR WIND SW) |
| M27 | 10A | Ignition Switch (IGN SW), Window Module (WIN MOD), PEM, Steering Column Lock |
| M28 | 10A | Next Generation Controller (NGC), PCM, Transmission Feed (TRANS FEED), TCM |
| M29 | 10A | Occupant Classification Module (OCM) |
| M30 | 15A | Rear Wiper Module (RR WIPER MOD), Power Folding Mirror (PWR FOLD MIR), J1962 Diagnostic Feed |
| M31 | 20A | Back-Up Lamps (B/U LAMPS) |
| M32 | 10A | Occupant Restraint Controller (ORC), TT EUROPE |
| M33 | 10A | Next Generation Controller (NGC), Global Powertrain Engine Controller (GPEC), TCM |
| M34 | 10A | Park Assist (PRK ASST), Heater Ventilation, Air Conditioning Module (HVAC MOD), Headlamp Wash (HDLP WASH), Compass (COMPAS), IR Sensor, Rear Camera, Lamp Door FT Drv/Pass, Lamp Flashlight, AHLM, Relay Diesel Cabin Heater, Rad Fan Diesel |
| M35 | 10A | Heated Mirrors |
| M36 | 20A | Power Outlet #3 (BATT) |
| M37 | 10A | Anti-Lock Brake System (ABS), Electronic Stability Program (ESP), Stop Lamp Switch (STP LP SW), Fuel Pump Rly Hi Control |
| M38 | 25A | Door Lock/Unlock Motors (LOCK/ UNLOCK MTRS), Liftgate Lock/Unlock Motors |
