Dodge Avenger 2009 Fuse Box Info
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 40A | Power Top Module (If Equipped) |
| 2 | 20A | AWD Module |
| 3 | 10A | Battery Feed — Center High Mounted Stop Light (CHMSL)/ Brake Switch |
| 4 | 10A | Battery Feed — Ignition Switch |
| 5 | 20A | Trailer Tow — If Equipped |
| 6 | 10A | Ignition Off Draw (IOD) — Power Mirror Switch/ Climate Controls |
| 7 | 30A | Ignition Off Draw (IOD) Sense 1 |
| 8 | 30A | Ignition Off Draw (IOD) Sense 2 |
| 9 | 40A | Battery Feed — Power Seats - if equipped/ PZEV Air Pump - if equipped |
| 10 | 20A | Battery Feed — Cabin Compartment Node (CCN) |
| 11 | 15A | Selectable Power Outlet |
| 12 | 20A | - |
| 13 | 20A | - |
| 14 | 10A | Ignition Off Draw (IOD) — Cabin Compartment Node (CCN)/ Interior Lighting |
| 15 | 40A | Battery Feed — Radiator Fan Relay |
| 16 | 15A | IGN Run/ ACC — Cigar Lighter/ PWR Sunroof Mod |
| 17 | 10A | Ignition Off Draw (IOD) — Wireless Control Module (WCM)/ Clock/ Steering Control Module (SCM) |
| 18 | 40A | Battery Feed — Auto Shutdown (ASD) Relay |
| 19 | 20A | Ignition Off Draw (IOD) — Power Amp Feed 2 - if equipped |
| 20 | 15A | Ignition Off Draw (IOD) — Radio |
| 21 | 10A | - |
| 22 | 10A | Ignition Run — Climate Controls/Hot Cup Holder - if equipped |
| 23 | 15A | Auto Shutdown (ASD) Relay Feed 3 |
| 24 | 25A | Battery Feed — PWR Sunroof Feed |
| 25 | 10A | Ignition Run — Heated Mirrors - If Equipped |
| 26 | 15A | Auto Shutdown (ASD) Relay Feed 2 |
| 27 | 10A | Ignition Run — Occupant Classification Module (OCM)/ Occupant Restraint Controller (ORC) |
| 28 | 10A | Ignition Run — Occupant Classification Module (OCM)/ Occupant Restraint Controller (ORC) |
| 29 | - | Hot Car (No Fuse Required) |
| 30 | 20A | Ignition Run — Heated Seats - If Equipped |
| 31 | 10A | - |
| 32 | 30A | Auto Shutdown (ASD) Relay Feed 1 |
| 33 | 10A | Battery Feed — Switch Bank/ Diagnostic Link Connector/ Powertrain Control Module (PCM) |
| 34 | 30A | Battery Feed — AntiLock Brakes (ABS) Module - if equipped/Electronic Stability Program (ESP) Module - If Equipped |
| 35 | 40A | Battery Feed — AntiLock Brakes (ABS) Module - If Equipped/Electronic Stability Program (ESP) Module - If Equipped |
| 36 | 30A | Battery Feed — Passenger Door Module (PDM)/Driver Door Module (DDM) |
| 37 | 25A | Power Top Module (If Equipped) |
