Chevrolet Colorado 2019 Fuse Box

Chevrolet Colorado 2019 Fuse Box Info



Passenger compartment fuse box location:

The instrument panel fuse box is behind the passenger side cowl side trim panel.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Functions
1 Run/Crank relay control/ Horn switch/Dome lamps
2 -
3 -
4 Steering Wheel Controls
5 Left headlamp low beam/ Front left park lamp/Left front side marker/Left rear side marker
6 -
7 -
8 Mirror Window Module
9 Instrument Panel Cluster
10 -
11 Door latches
12 -
13 OnStar/HVAC
14 Radio/Infotainment
15 RAP accessory relay control/Shifter control/ Shifter solenoid/Wiper relay control/Washer pump relay control/Rear defog relay control
16 Communication gateway module
17 Left rear side marker/ Right front turn lamp/Left rear stop lamp/Left front turn lamp/Right rear stop lamp
18 Airbag/Sensing and diagnostic module/ Automatic occupant sensing module
19 -
20 Amplifier
21 -
22 -
23 Data link connector/USB front
24 HVAC ignition
25 Driver door latch
26 -
27 -
28 Instrument panel cluster and automatic sensing display
29 Rear vision camera/ Transfer case control module (4WD)/Inside rear view
30 -
31 Front camera/Rear park assist
32 Steering Wheel Controls Backlighting
33 Heated steering wheel/ Spare
34 Spare
35 Park/Reverse/Neutral/ Drive/Low display/ Wireless charging module/USB rear
36 Discrete Logic Ignition Sensor
37 -
38 -
39 Auxiliary Power Outlet 2
40 -
41 Auxiliary power outlet 1/ Cigarette lighter
42 Left Power Window
43 Driver Power Seat
44 Auxillary power outlet
45 Right Power Window
46 Passenger Power Seat
K1 Retained Accessory Power
K2 Run/Crank





Engine compartment fuse box:

Fuse/Relay N° Functions
1 Traction Control Module Power
2 Engine Control Module Power
3 Air Conditioning Clutch
4 -
5 Engine control module/ Integrated chassis control module/Fuel pump power module
6 Wipers
7 Cargo lamp/Bed lighting (if equipped)
8 Fuel Injectors - Even
9 Fuel Injectors - Odd
10 Engine control module 1
11 Oxygen/Mass air flow/ Humidity/Induction air temperature/Throttle inlet pressure sensors
12 Starter
13 Traction Control Module
14 -
15 -
16 -
17 Front Axle Actuator
18 -
19 Aeroshutters
20 -
21 Front Blower
22 Antilock Brake System Valves
23 -
24 Trailer
25 Transfer Case Electronic Control
26 Antilock Brake System Pump
27 Trailer brake control module
28 Rear Window Defogger
29 -
30 Driver heated seat
31 -
32 Passenger heated seat
33 Right headlamp low beam/FRT right park lamp/Right front side marker/Right rear side marker
34 Fuel pump power module
35 Integrated chassis control module
36 Center High Mounted Stop Lamp
37 Right High-Beam Headlamp
38 Left High-Beam Headlamp
39 Rear differential lock actuators
40 Front differential lock actuators
41 -
42 -
43 -
44 -
45 Vacuum pump
46 Engine control module ignition 2
47 Mid park phase lock/ Active fuel management/Engine oil and canister purge solenoid(s)/Oxygen sensor
48 Fog Lamps
49 -
50 Trailer Parking Lamps
51 Horn
52 -
53 -
54 -
55 -
56 Washer Pump
57 -
58 -
59 -
60 Mirrors Defogger
61 -
62 Canister Vent Solenoid
63 -
64 Trailer Reverse Lamp
65 Left trailer stoplamp/Turn signal lamps
66 Right trailer stoplamp/Turn signal lamps
67 Electric Power Steering
68 -
69 Battery Regulated Voltage Control
70 -
71 -
72 -
73 -
74 Generator
75 -
K01 Air Conditioning Clutch
K02 Starter
K03 -
K04 Wipers Speed
K05 Wipers Control
K06 Cargo lamp/Bed lighting
K07 Powertrain
K08 -
K09 Rear differential lock actuators
K10 Front differential lock actuators
K11 Center high-mounted stoplamp
K12 -
K13 Vacuum Pump
K14 Trailer parking lamps
K15 Run/Crank
K16 -
K17 Rear window/Mirror defogger
