Chevrolet Colorado 2015 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is behind the passenger side cowl side trim panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Functions |
| 01 | Body Control Module 1 |
| 02 | Not Used |
| 03 | Not Used |
| 04 | Steering Wheel Controls |
| 05 | Body Control Module 2 |
| 06 | Not Used |
| 07 | Not Used |
| 08 | Mirror Window Module |
| 09 | Instrument Cluster |
| 10 | Not Used |
| 11 | Body Control Module 8 |
| 12 | Not Used |
| 13 | OnStar/Heating, Ventilation, and Air Conditioning |
| 14 | Radio/HMI |
| 15 | Body Control Module 6 |
| 16 | Not Used |
| 17 | Body Control Module 4 |
| 18 | Airbag |
| 19 | Not Used |
| 20 | Amplifier (if equipped) |
| 21 | Not Used |
| 22 | Not Used |
| 23 | Data Link Connector/USDB |
| 24 | Heating, Ventilation, and Air Conditioning Ignition |
| 25 | Body Control Module 7 |
| 26 | Not Used |
| 27 | Not Used |
| 28 | Instrument Panel/ Sensing and Diagnostic Module Ignition |
| 29 | Miscellaneous Ignition |
| 30 | Not Used |
| 31 | Front Camera |
| 32 | Steering Wheel Controls Backlighting |
| 33 | Not Used |
| 34 | Not Used |
| 35 | Park, Reverse, Neutral, Drive, Low |
| 36 | Discrete Logic Ignition Sensor |
| 37 | Not Used |
| 38 | Not Used |
| 39 | Auxiliary Power Outlet 2 |
| 40 | Auxiliary Power Outlet |
| 41 | Auxiliary Power Outlet 1/Lighter |
| 42 | Left Power Window |
| 43 | Driver Power Seat |
| 44 | Auxiliary Power Outlet |
| 45 | Right Power Window |
| 46 | Passenger Power Seat |
| K1 | Retained Accessory Power/Accessory |
| K2 | Run/Crank |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 01 | Traction Control Module Power |
| 02 | Engine Control Module Power |
| 03 | Air Conditioning Compressor Clutch |
| 04 | Not Used |
| 05 | Fuel Module Ignition |
| 06 | Wipers |
| 07 | Cargo Lamp |
| 08 | Fuel Injectors - Even |
| 09 | Fuel Injectors - Odd |
| 10 | Engine Control Module |
| 11 | Miscellaneous 1 Ignition |
| 12 | Starter |
| 13 | Traction Control Module |
| 14 | Not Used |
| 15 | Not Used |
| 16 | Not Used |
| 17 | Front Axle Actuator |
| 18 | Not Used |
| 19 | Aeroshutters |
| 20 | Not Used |
| 21 | Front Blower |
| 22 | Antilock Brake System Valves |
| 23 | Not Used |
| 24 | Trailer |
| 25 | Transfer Case Electronic Control |
| 26 | Antilock Brake System Pump |
| 27 | Trailer Brake Control Module |
| 28 | Rear Window Defogger |
| 29 | Not Used |
| 30 | Heated Seat Power 1 |
| 31 | Not Used |
| 32 | Heated Seat Power 2 |
| 33 | Body Control Module 3 |
| 34 | Fuel System Control Module |
| 35 | Not Used |
| 36 | Center High Mounted Stop Lamp |
| 37 | Right High-Beam Headlamp |
| 38 | Left High-Beam Headlamp |
| 39 | Not Used |
| 40 | Not Used |
| 41 | Not Used |
| 42 | Not Used |
| 43 | Cooling Fan |
| 44 | Not Used |
| 45 | Brake Vacuum Pump |
| 46 | Not Used |
| 47 | Miscellaneous 2 Ignition |
| 48 | Fog Lamps (If Equipped) |
| 49 | Not Used |
| 50 | Trailer Park Lamps |
| 51 | Horn |
| 52 | Not Used |
| 53 | Not Used |
| 54 | Not Used |
| 55 | Not Used |
| 56 | Washer Pump |
| 57 | Not Used |
| 58 | Not Used |
| 59 | Not Used |
| 60 | Mirrors Defogger |
| 61 | Not Used |
| 62 | Canister Vent Solenoid |
| 63 | Not Used |
| 64 | Trailer Reverse Lamp |
| 65 | Left Trailer Stop/ Turn Lamps |
| 66 | Right Trailer Stop/ Turn Lamps |
| 67 | Electric Power Steering |
| 68 | Not Used |
| 69 | Battery Regulated Voltage Control |
| 70 | Not Used |
| 71 | Not Used |
| 72 | Not Used |
| 73 | Not Used |
| 74 | Generator |
| 75 | Not Used |
| K01 | Air Conditioning Compressor Clutch |
| K02 | Starter |
| K03 | Not Used |
| K04 | Wipers Speed |
| K05 | Wipers Control |
| K06 | Cargo Lamp |
| K07 | Powertrain |
| K08 | Not Used |
| K09 | Not Used |
| K10 | Not Used |
| K11 | Center High Mounted Stop Lamp |
| K12 | Not Used |
| K13 | Vacuum Pump |
| K14 | Park Lamps |
| K15 | Run/Crank |
| K16 | Not Used |
| K17 | Rear Window Defogger |
